Page 466 - Keubler Motion Sensors

Connection technology

M12 connection technology Cordsets, pre-assembled

www.HydroSanatSharif.com
With connector, 5 pin Working temp. -30°C ... +80°C [-22°F ... +176°F] Order no.
Female connector with coupling nut + Bus in / out suitable for our series:
male connector with external thread
B coded, straight
Cable: PUR, 2 x 0.34 mm 2 2) 2) 5858 / 5878
2 2
Housing: metal / plastic, IP67 5868 / 5888
1 5 3 3 5 1 9080
4 4

Cable length 1)
2 m [6.56‘] 05.00.6011.3432.002M
5 m [16.40‘] 05.00.6011.3432.005M
10 m [32.81‘] 05.00.6011.3432.010M
15 m [49.21‘] 05.00.6011.3432.015M

Female connector with coupling nut + Bus in / out suitable for our series:
male connector with external thread
B coded, right-angle
Cable: PUR, 2 x 0.34 mm 2 2) 2) 5858 / 5878
2 2
Housing: metal / plastic, IP67 5868 / 5888
1 5 3 3 5 1 9080
4 4

Cable length 1)
2 m [6.56‘] 05.00.6011.3533.002M
5 m [16.40‘] 05.00.6011.3533.005M
10 m [32.81‘] 05.00.6011.3533.010M
15 m [49.21‘] 05.00.6011.3533.015M

1) Other cable lengths on request.
2) Shield on housing.
