Connection technology

M12 connection technology Cordsets, pre-assembled

www.HydroSanatSharif.com
With connector, 8 pin Working temp. -30°C ... +80°C [-22°F ... +176°F] Order no.
Female connector with coupling nut + suitable for our series:
single-ended
A coded, straight
2
Cable: PVC, 8 x 0.25 mm [AWG23] 3610 / 3620 5000 / 5020
2
Housing: metal / plastic, IP67 3 5814 / 5834 5814FSx / 5834FSx
1 8 4 5006 / 5026 5821
7 5 A020 / A02H
6
F3653 / F3673
5853 / 5873
M3663 / M3683 M3663R / M3683R
F3663 / F3683 F5863 / F5883
5863 / 5883
5876
Terminal assignment Cable length 1)
Pin female contacts: 1 2 3 4 5 6 7 8 PH 2) 2 m [6.56‘] 05.00.6041.8211.002M
Wire colour: WH BN GN YE GY PK BU RD PH 2) 5 m [16.40‘] 05.00.6041.8211.005M
10 m [32.81‘] 05.00.6041.8211.010M
15 m [49.21‘] 05.00.6041.8211.015M

Female connector with coupling nut + suitable for our series:
single-ended
A coded, straight
2
Cable: PUR, 8 x 0.25 mm [AWG23] 3610 / 3620 5000 / 5020
2
Housing: metal / plastic, IP67 3 5814 / 5834 5814FSx / 5834FSx
1 8 4 5006 / 5026 5821
7 5 A020 / A02H
6
F3653 / F3673
5853 / 5873
M3663 / M3683 M3663R / M3683R
F3663 / F3683 F5863 / F5883
5863 / 5883
5876
Terminal assignment Cable length 1)
Pin female contacts: 1 2 3 4 5 6 7 8 PH 2) 2 m [6.56‘] 05.00.6051.8211.002M
Wire colour: WH BN GN YE GY PK BU RD PH 2) 5 m [16.40‘] 05.00.6051.8211.005M
10 m [32.81‘] 05.00.6051.8211.010M
15 m [49.21‘] 05.00.6051.8211.015M
Connection
Female connector with coupling nut + suitable for our series: technology
single-ended
A coded, right-angle
2
Cable: PVC, 8 x 0.25 mm [AWG23] 2 3610 / 3620 5000 / 5020
3
Housing: metal / plastic, IP67 1 8 4 5814 / 5834 5814FSx / 5834FSx
7 5 5006 / 5026 5821
6
A020 / A02H
F3653 / F3673
5853 / 5873
M3663 / M3683 M3663R / M3683R
F3663 / F3683 F5863 / F5883
5863 / 5883
5876
Terminal assignment Cable length 1)
Pin female contacts: 1 2 3 4 5 6 7 8 PH 2) 2 m [6.56‘] 05.00.6041.8311.002M
Wire colour: WH BN GN YE GY PK BU RD PH 2) 5 m [16.40‘] 05.00.6041.8311.005M
10 m [32.81‘] 05.00.6041.8311.010M
15 m [49.21‘] 05.00.6041.8311.015M

1) Other cable lengths on request.
2) Shield on housing.
© Fritz Kübler GmbH, subject to errors and changes. 02/2015 www.kuebler.com 465
