Connection technology
M23 connection technology Connectors, self-assembly
www.HydroSanatSharif.com
12 pin Order no.
Female connector with coupling nut solder connections, suitable for: 8.0000.5012.0000.Ex
pin socket assignment cw for cable ø 5.5 ... 10.5 mm [0.22 ... 0.41“]
(EX zone 2/22 on request)
Housing: metal, IP67 5000 / 5020 580X / 582X
8 9 1 5814 / 5834 5814FSx / 5834FSx
7 2
F5863 / F5883
12 10
6 3 585X / 587X 5853FSx /5873FSx
11
5 4 586X / 588X 5863FSx /5883FSx
9000 908X
A02X
60 [2.36]
56 [2.20]
ø26,5 [1.04]
17 pin Order no.
Female connector with coupling nut solder connections, suitable for: 8.0000.5042.0000
pin socket assignment ccw for cable ø 5.5 ... 10.5 mm [0.22 ... 0.41“]
Housing: metal, IP67 5850 / 5870
11 10
1 5852 / 5872
12 16
2 17
13 15 8
14
3
7
4 6
5
60 [2.36]
56 [2.20]
ø26,5 [1.04]
468 www.kuebler.com © Fritz Kübler GmbH, subject to errors and changes. 02/2015
