Connection technology

M23 connection technology Connectors, self-assembly

www.HydroSanatSharif.com
12 pin Order no.
Male connector with external thread solder connections, suitable for: 8.0000.5015.0001
pin assignment ccw for cable ø 5.5 ... 10.5 mm [0.22 ... 0.41“]
Housing: metal, IP67 versions with cable outlet
1 9 8
2
7
10 12
3
11 6
4
5
60 [2.36]
56 [2.20]
ø26,5 [1.04]

Male connector with external thread solder connections, suitable for: 8.0000.5015.0000
pin assignment ccw for cable ø 5.5 ... 10.5 mm [0.22 ... 0.41“]
central fastening
Housing: metal, IP67 versions with cable outlet
1 9 8
2
7
10 12
3
11 6
4
5

0 [

Female connector with coupling nut solder connections, suitable for: 8.0000.5012.0000
pin socket assignment cw for cable ø 5.5 ... 10.5 mm [0.22 ... 0.41“]
Housing: metal, IP67 5000 / 5020 580X / 582X
8 9 1 5814 / 5834 5814FSx / 5834FSx
7 2 Connection
F5863 / F5883 technology
12 10
6 3 585x / 587x 5853FSx /5873FSx
11
5 4 586x / 588x 5863FSx /5883FSx
9000 908x
60 [2.36] A02x
56 [2.20]
ø26,5 [1.04]
M23

© Fritz Kübler GmbH, subject to errors and changes. 02/2015 www.kuebler.com 467
