Connection technology

M12 connection technology Connectors, self-assembly

T-junction www.HydroSanatSharif.com
Accessories Order no.
Securing clip for M12 connectors against accidental disconnection under 8.0000.5000.0006
load
Material: plastic working temperature range
-25°C ... +90°C [-13°F ... +194°F]

Terminating resistor suitable for our series: 05.RSS4.5-PDP-TR
Male connector with external thread
B coded, straight
Housing: metal / plastic, IP67 5858 / 5878
5868 / 5888
9080

0 [

Terminating resistor suitable for our series: 05.RSE 57 TR2
Male connector with external thread
A coded, straight
Housing: metal / plastic, IP67 F5868 / F5888
5858 / 5878
5868 / 5888
9080
42,9 [1.69]
18,2 [0.72]
16,4 [0.65] ø15 [0.59]

M12 lead-through suitable for our series: 05.FKW-FSW45/M12
B coded, straight
Housing: metal, IP67 5858 / 5878
2
5868 / 5888
3 5 1 9080
4

2 x female connector with coupling nut suitable for: 05.FKM5-FKM5-FSM5
A coded, 5 pin 1 x male connector with external thread
Housing: metal / plastic, IP67 M12 connectors
2 2
1 5 3 3 5 1
4 4
