Connection technology

M12 connection technology Connectors, self-assembly

www.HydroSanatSharif.com
5 pin Order no.
Female connector with coupling nut screw connections, suitable for our series: 8.0000.5116.0000
A coded, straight for cable ø 6 ... 8 mm [0.24 ... 0.32“]
Housing: metal, IP67 A50, B80, C120, D135,
2
IS40
1 5 3 3651 / 3671
4
F3658 / F3658
F3668 / F3688
M3658 / M3678

M3668 / M3688
M3668R / M3688R
F5868 / F5888

5858 / 5878
5868 / 5888
9080
IS60
Female connector with coupling nut screw connections, suitable for our series: 05.B-8151-0/9
A coded, straight for cable ø 6 ... 8 mm [0.24 ... 0.32“]
Housing: plastic, IP67 A50, B80, C120, D135,
2
IS40
1 5 3 3651 / 3671
4
9080
IS60

Female connector with coupling nut screw connections, suitable for our series: 05.B-8251-0/9
A coded, right-angle for cable ø 6 ... 8 mm [0.24 ... 0.32“]
Housing: plastic , IP67 A50, B80, C120, D135,
2
IS40
1 5 3 3651 / 3671
4
9080
IS60
