P. 456
Connection technology
M12 connection technology Connectors, self-assembly
www.HydroSanatSharif.com
5 pin Order no.
Female connector with coupling nut screw connections, suitable for our series: 05.BMWS 8151-8.5
B coded, straight for cable ø 4 ... 9 mm [0.16 ... 0.35“]
Housing: metal, IP67 5858 / 5878
2 5868 / 5888
1 5 3 9080
4
Female connector with coupling nut screw connections, suitable for our series: 05.BMWS 8251-8.5
B coded, right-angle for cable ø 4 ... 9 mm [0.16 ... 0.35“]
Housing: metal, IP67 5858 / 5878
2
5868 / 5888
1 5 3 9080
4
Male connector with external thread screw connections, suitable for our series: 05.BMSWS 8151-8.5
B coded, straight for cable ø 4 ... 9 mm [0.16 ... 0.35“]
Housing: metal, IP67 5858 / 5878
2
5868 / 5888
3 5 1 9080
4
Male connector with external thread screw connections, suitable for our series: 05.BMSWS 8251-8.5
B coded, right-angle for cable ø 4 ... 9 mm [0.16 ... 0.35“]
Housing: metal, IP67 5858 / 5878
2
5868 / 5888
3 5 1 9080
4
454 www.kuebler.com © Fritz Kübler GmbH, subject to errors and changes. 02/2015
