Connection technology

M23 connection technology Cordsets, pre-assembled

www.HydroSanatSharif.com
With connector, 12 pin Working temp. -30°C ... +80°C [-22°F ... +176°F] Order no.
Female connector with coupling nut + pin socket pin socket suitable for our series:
male connector with external thread assignment cw assignment ccw
Cable: PVC, 6 x 2 x 0.14 mm [AWG25] 2) 2) 5000 / 5020 5803 / 5823
2
8 9 1 1 9 8
Housing: metal, IP67 5804 / 5824 5805 / 5825
7 2 2
7 5814 / 5834 5814FSx / 5834FSx
6 12 10 3 3 10 12
11 11 6 A020 / A02H H120
5 4 4
5
60 [2.36]
56 [2.20]
ø26,5 [1.04]

60 [2.36]
56 [2.20]

ø26,5 [1.04] 2 m [6.56‘] 8.0000.6905.0002
M23 Cable length 1)
5 m [16.40‘]
10 m [32.81‘] 8.0000.6905.0005
8.0000.6905.0010
15 m [49.21‘] 8.0000.6905.0015

Female connector with coupling nut + pin socket pin socket suitable for our series with SSI
male connector with external thread assignment cw assignment ccw output:
Cable: PVC, 6 x 2 x 0.14 mm [AWG25] 2) 2) 5850 / 5870 F5863 / F5883
2
8 9 1 1 9 8
Housing: metal, IP67 5853 / 5873 5853FSx / 5873FSx
7 2 2
7 5863 / 5883 5863FSx / 5883FSx
6 12 10 3 3 10 12
11 11 6 9081
5 4 4
5
60 [2.36]
56 [2.20]
ø26,5 [1.04] Connection technology

60 [2.36]
56 [2.20]
Cable length 1)
ø26,5 [1.04] 5 m [16.40‘] 8.0000.6905.0005.0032
M23 2 m [6.56‘] 8.0000.6905.0002.0032

10 m [32.81‘] 8.0000.6905.0010.0032
15 m [49.21‘] 8.0000.6905.0015.0032

1) Other cable lengths on request.
2) Shield on housing.
