Linear measuring technology

Draw wire mechanics Measuring length max. 0.6 m
with analogue sensor Draw wire encoder A30 Traverse speed max. 0.8 m/s
www.HydroSanatSharif.com
Technical data
Mechanical characteristics (draw wire mechanics) Electrical characteristics
Speed max. 0.8 m/s Analogue output 0 ... 10 V DC 4 ... 20 mA potentiometer
Working temperature -10°C ... +80°C [+14°F ... +176°F] 10 k1
Protection acc. to EN 60529 IP50 Power supply 15 ... 28 V DC – –
Weight approx. 60 g [2.12 oz] Operating range – 15 ... 28 V DC max. 48 V DC
Extension force F min 3 N Max. load current 15 mA – –
Repeat accuracy ±0.15 mm Load – max. 500 1 –
Linearity ±0.35 % Temperature range -10°C ... +80°C [+14°F ... +176°F]
Material housing plastic CE compliant acc. to EMC guideline 2004/108/EC
wire stainless-steel ø 0.4 mm RoHS guideline 2011/65/EU
plastic-coated

Terminal assignment
Colour BN WH GN
0 ... 10 V DC + 24 V DC 0 V U out
4 ... 20 mA +I -I n.c.
Potentiometer Po Pe S

R/U converter R/I converter Potentiometer
0 ... 10 V DC +V 4 ... 20 mA I+ Pe
U out S
Linear measuring technology
10 kΩ 10 kΩ 10 kΩ
I-
0 V
Po
Dimensions
Dimensions in mm [inch]

© Fritz Kübler GmbH, subject to errors and changes. 02/2015 www.kuebler.com 401
