Linear measuring technology

Draw wire mechanics Draw wire encoder A40, 1 m Measuring length max. 2 m
with analogue sensor Draw wire encoder A41, 2 m Traverse speed max. 1 m/s
www.HydroSanatSharif.com
Technical data
Mechanical characteristics (draw wire mechanics) Electrical characteristics
Measuring range 1000 mm (A40) 2000 mm (A41) Analogue output 0 ... 10 V 4 ... 20 mA potentiometer
Speed max. 0.8 m/s 1 m/s 10 k1
Working temperature 0°C ... 50°C [+32°F ... +122°F] -10°C ... +80°C [+14°F ... +176°F] Power supply 15 ... 28 V DC – –
Protection IP50 IP65 Operating range – 15 ... 28 V DC max. 48 V DC
acc. to EN 60529 Temperature range 0°C ... 50°C 0°C ... 50°C 0°C ... 50°C
Weight approx. 200 g [7.06 oz] approx. 320 g [11.29 oz] [+32°F ... +122°F] [+32°F ... +122°F] [+32°F ... +122°F]
Extension force F min 2 N Load max. 500 1 max. 500 1 –
CE compliant acc. to EMC guideline 2004/108/EC
Repeat accuracy ±0.15 mm
RoHS guideline 2011/65/EU
Linearity ±0.35 %
Material housing plastic / zinc die-cast
wire stainless-steel ø 0.45 mm plastic-coated
Terminal assignment
Colour BN WH GN
Pin M12 1 2 3 4
0 ... 10 V + 24 V DC 0 V U out n.c.
0 ... 20 mA I+ I- n.c. n.c.
Potentiometer Po Pe S n.c.

R/U converter +V R/I converter I+ Potentiometer Pe
0 ... 10 V 4 ... 20 mA
U out S
10 kΩ 10 kΩ 10 kΩ
I-
0 V Po Linear measuring technology

Dimensions
Dimensions in mm [inch]
for measuring range 1000 mm for measuring range 2000 mm
M 6 5 [0.2]
cable connection max. 5 [0.2]
25 [0.98]
0 1 44 [1.72]
PLQ ca.14,5 [0.57] 8 [0.32]

31 [1.22]

72,3 [2.85] 41 [1.62]

6,5 [0.26]

11,2 [0.44] 26 [1.02]
M12 connector

[0.45] M12x1 1 8 [0.32]
11,5

31 [1.22]
1 2 x M4, max. screw-in depth 8 mm [0.32“]

72,3 [2.85]

© Fritz Kübler GmbH, subject to errors and changes. 02/2015 www.kuebler.com 403
6,5 [0.26]
