Absolute encoders – multiturn

Standard
electronic multiturn, optical Sendix F5863 / F5883 (shaft / hollow shaft) SSI / BiSS
www.HydroSanatSharif.com
Dimensions shaft version
Dimensions in mm [inch]

Clamping flange, ø 58 [2.28]
Flange type 1 and 3
(drawing with M23 connector)
1 3 x M3, 6 [0.24] deep
2 3 x M4, 8 [0.32] deep
> @ > @ '
> @
> @ [ ƒ
/
ƒ
D L Fit
6 [0.24] 10 [0.39] h7 > @
10 [0.39] 20 [0.79] f7 > @

1/4“ 7/8“ h7
3/8“ 7/8“ h7

Synchro flange, ø 58 [2.28]

Flange type 2 and 4
(drawing with M12 connector)
1 M4, 6 [0.24] deep

K > @ '

> @ [ ƒ
/

ƒ

D L Fit
6 [0.24] 10 [0.39] h7
10 [0.39] 20 [0.79] f7
1/4“ 7/8“ h7
3/8“ 7/8“ h7
