Accessories

Connection of motor and encoder Flexible shaft coupling Double loop coupling

The safe, uncomplicated and economical solution, if drive shafts
with angular, radial and/or axial displacement are to be friction-
locked together.

Order no. size 1 Order no. size 2

Bore diameter both sides 6 mm [0.24“] 8.0000.1J01.0606 Bore diameter both sides 10 mm [0.39“] 8.0000.1K01.1010
Bore diameter 11 mm [0.43“] and 12 mm [0.47“] 8.0000.1L01.1112
with keyway

Functional principle
Technical data
Compensation of an angular misalignment Compensation of a radial misalignment
Size 1 Size 2
-1
Max. speed 3000 min 3000 min -1
Max. torque 0.5 Nm 2,0 Nm
Max. offset of shafts radial ± 2 mm ± 3 mm
± 4 mm
axial ± 2 mm

10 / 10 www.HydroSanatSharif.com
angular ± 10° ± 12°
Torsion spring stiffness 13 Nm/rad 28 Nm/rad
Radial spring stiffness 13 N/mm 7 N/mm
Moment of intertia 41 gcm² 106 gcm² Compensation of a axial misalignment
Max. clamping torque 100 Ncm 100 Ncm
Weight, approx. 33 g [1.16 oz] 85 g [3.35 oz]
Temperature range -30°C ... + 80°C [-22°F ... +176°F]
Material flange steel galvanized
conecting element Polyurethane

Dimensions
Dimensions in mm
+
Size 1 Size 2 4 JS9 (- 0,015)
0,015
6 / 6 2,5 [0.10] 11 / 12 [0.43 / 0.47] 0,1
+
[0.24 / 0.24] with keyway 1 2,8 - 0
ø6 h8 [0.24] ø6 h8 [0.24] ø29 ±1 [1.14] 48 1 12 H8(- 0 ) Accessories
0,027
+

4x DIN916 M3 x 4 [0.16] 29 ±1,5 [1.14]

Size 2 2
9 [0.35] 46 +
0,027
11H8(- 0 )
[0.39 / 0.39]
9
+
+
0,027
ø10 h8 [0.39] ø10 h8 [0.39] ø48 ±1 [1.89] 11H8(- 0 ) 1 3,8 - 0 0,1 + 4 JS9 (- 0,015)
0,015

4x DIN916 M4 x 6 [0.24] 46 ±2 [1.81]
