Accessories
General accessories
www.HydroSanatSharif.com
Dimensions / Details Dimensions in mm [inch] Order no.
Screw retention Loctite 243 (5 ml) Chemical basis: dimethacrylate ester 8.0000.4G05.0000
Components: single-component
(no mixing required)
Viscosity: medium, thixotrope
Cure: anaerobic
Secondary cure: activator
Use: screw retention
Strength: medium
EMC shield terminal For an EMC-compliant installation of the 8.0000.4G06.0000
11,8 encoder cable,
[0.46]
top-hat rail mounting,
Shield diameter 3.0 ... 6.0 mm,
~ 21 [0.83] Clamp (spring steel, galvanised)
Foot (spring steel)
~ 49 [1.93]
14
~ 56,9 [2.24] [0.55]
Stylus for the set key For easy operation of the set key 8.0010.4052.0000
on the encoder
! Material POM (HKS8 orange) !
" "
# #
