Absolute encoders – multiturn

Large hollow shaft
optical / magnetic 9081 (hollow shaft) SSI
www.HydroSanatSharif.com
Technical data
Mechanical characteristics SSI interface
-1
-1
Maximum speed 6000 min , 3000 min (continuous) Output driver RS485
-6
Mass moment of inertia approx. 65 x 10 kgm 2 Permissible load / channel max. +/- 20 mA
Starting torque - at 20°C [68°F] < 0.2 Nm Update rate for position data approx. 1600/s
Weight approx. 0.7 kg SSI clock rate min. / max. 100 kHz / 500 kHz
Protection acc. to EN 60529 IP65 Signal level HIGH typ. 3.8 V
LOW (l Load = 20 mA) typ. 1.3 V
Working temperature range -20°C ... +70°C [-4°F ... +158°F]
Resolution singleturn 1 ... 8192 (13 bit), scaleable
Materials hollow shaft stainless steel H7
Number of revolutions (multiturn) 1 ... 4096 (12 bit), scaleable
2
Shock resistance acc. to EN 60068-2-27 2500 m/s , 6 ms
Falling edge time t f (without cable) max. 100 ns
2
Vibration resistance acc. to EN 60068-2-6 100 m/s , 10 ... 2000 Hz
Rising edge time t r (without cable) max. 100 ns
Electrical characteristics
Control outputs
Power supply 5.0 ... 30 V DC 4)
Output driver Push-Pull
Power consumption typ. 89 mA
(no load) max. 138 mA Max. current output ± 10.0 mA
2)
Short circuit proof outputs yes 3) Signal level HIGH min. +V - 2.8 V
LOW max. 1.8 V
Reverse polarity protection yes
of the power supply Falling edge time t f (without cable) max. 1 µs
Performance against magnetic EN 61000-4-8, severity level 5 Rising edge time t r (without cable) max. 1 µs
influence acc. to
UL approval file 224618
CE compliant acc. to EMC guideline 2004/108/EC
RoHS guideline 2011/65/EU
Control inputs (V/R, SET)
Voltage 5 ... 30 V DC = +V
Response time 10 ms
Switching level LOW max. 25% +V
HIGH min. 60% +V, max. +V
Max. current load 0.5 mA

Control inputs
V/R input for change of direction Note:
The encoder can output increasing code values when the shaft is rotated either • Any hardware configuration of the V/R input must take place BEFORE
clockwise or counter-clockwise (when looking from the shaft side). powering up the encoder!
The appropriate option can be selected via a hardware configuration of the V/R • If the V/R input is not configured, then a 0 V configuration will apply
input BEFORE powering up the encoder. (default condition)!
The following table shows the function selection dependent on hardware and • If the direction of rotation is changed due to the V/R configuration, without
software settings: activating the SET function again, and if the encoder is also then powered
up again, a new position value may be outputted, even if the physical shaft
Hardware configuration Function: position of the encoder has not moved! This is due to internal conversion
of the V/R input: increasing code value when the shaft is in the processes.
following direction
• The start-up procedure for the encoder should therefore follow this sequence:
„LOW“ 1. Determine the count direction of the encoder either via the V/R input or via
(0V) on the V/R input (=cw) cw
programming
„HIGH“ 2. Apply power to the encoder
(+V) on the V/R input (= ccw) ccw
3. Activate the SET function, if desired (see SET input below)
„LOW“
(0V) on the V/R input (=cw) ccw • If using a cable wire to configure the V/R input, then for EMC reasons the wire
should not remain open but should be tied either to 0 V or +V!
„HIGH“
(+V) on the V/R input (= ccw) ccw • The response time of the V/R input with +V = 5 ... 30 V DC power supply is
10 ms.
3) Only one channel allowed to be shorted-out:
1) For shaft version only (at shaft end). at +V = 5 V DC short circuit to channel, 0 V, or +V is permitted.
2) If power supply +V correctly applied. at +V * 5 ... 30 V DC short circuit to channel or 0 V is permitted.
4) The power supply at the encoder input must not be less than 4.75 V (5 V - 5%).
