Linear measuring technology

Type Description Page
www.HydroSanatSharif.com
Incremental magnetic Sensor head, magnetic band Limes LI20 / B1 Resolution min. 10 µm 386
measurement system Sensor head, magnetic band Limes LI50 / B2 Resolution min. 5 µm 389

Absolute magnetic Sensor head, magnetic band Limes LA10 / BA1 Resolution min. 1 µm 392

measurement system Sensor head, magnetic band Limes LA50 / BA5 Resolution min. 10 µm 396

Draw wire mechanics With analogue sensor Draw wire encoder A30 Measuring length max. 0.6 m 400
With analogue sensor Draw wire encoder A40 Measuring length max. 1 m 402
With encoder or analogue sensor Draw wire encoder A50 Measuring length max. 1.25 m 404
With incremental encoder Draw wire encoder A40 Measuring length max. 2 m 407
With analogue sensor Draw wire encoder A41 Measuring length max. 2 m 402
With absolute encoder Draw wire encoder A41 Measuring length max. 2 m 409
With encoder or analogue sensor Draw wire encoder B75 Measuring length max. 3 m 411
With encoder or analogue sensor Draw wire encoder B80 Measuring length max. 3 m 414
With encoder Draw wire encoder C105 Measuring length max. 6 m 417

With encoder or analogue sensor Draw wire encoder C120 Measuring length max. 6 m 419
With encoder or analogue sensor Draw wire encoder D135 Measuring length max. 42.5 m 422
Linear measuring
Lift measuring system For shaft-copying Encoder mounting fixture, Max. height 53 m 427 technology
guided-belt, LM3

Length measuring kit With encoder Mini measurement system Incremental 429
With encoder / preset counter With rack and pinion Incremental / absolute 430
With encoder / preset counter Measuring wheelsystem Incremental / absolute 431

Flexible fastening Spring encoder arm 432
Measuring wheels Various wheel coatings 433
