Absolute encoders - singleturn

Standard
optical Sendix 5858 / 5878 (shaft / hollow shaft) CANopen
www.HydroSanatSharif.com

The singleturn encoders 5858 and 5878 with CANopen interface
and optical sensor technology are ideal for use in all CANopen
applications.
They offer a maximum resolution of 16 bits, divided over 360°.
These encoders are available with blind hollow shaft up to 15 mm.

RoHS
2/22

-40°... +80°C IP
Safety-Lock TM High rotational Temperature High protection High shaft load Shock / vibration Magnetic field Magnetic field Reverse polarity Optical sensor Surface protection
speed range level capacity resistant proof proof protection salt spray-tested
optional
Reliable Flexible
• Tried-and-tested in applications with the highest demands, • Node address can be set via rotary switches or software.
such as in mobile automation or medical technology. • Baud rate and termination can be set via DIP switches or
• Ideal for use outdoors thanks to IP67 protection and wide software.
temperature range from -40°C up to +80°C. • With bus terminal cover or fixed connection, as well as M12
connectors or cable connection.

Order code 8.5858 . X X 2 X . 21 1 X If for each parameter of an encoder the underlined preferred option is selected,
then the delivery time will be 10 working days for a maximum of 10 pieces.
Shaft version Type a b c d e f Qts. up to 50 pcs. of these types generally have a delivery time of 15 working days.
a Flange d Type of connection e Fieldbus profile 3)
1 = clamping flange, IP65 ø 58 mm [2.28“] removable bus terminal cover 21 = CANopen encoder profile DS406 V3.2
3 = clamping flange, IP67 ø 58 mm [2.28“] 1 = radial cable gland
2 = synchro flange, IP65 ø 58 mm [2.28“] 2 = 2 x M12 connector f Options (service)
4 = synchro flange, IP67 ø 58 mm [2.28“] Fixed connection without bus terminal cover 2 = no options
5 = square flange, IP65 63.5 mm [2.5“] A = radial cable, 2 m [6.56‘] PVC 3 = SET button
7 = square flange, IP67 63.5 mm [2.5“] B = radial cable, special length PVC *)
E = 1 x radial M12 connector, 5-pin Optional on request
b Shaft (ø x L), with flat F = 2 x radial M12 connector, 5-pin - Ex 2/22
1 = 6 x 10 mm [0.24 x 0.39“] 1) I = 1 x radial M23 connector, 12-pin - surface protection
2 = 10 x 20 mm [0.39 x 0.79“] 2) J = 2 x radial M23 connector, 12-pin salt spray tested
3 = 1/4“ x 7/8“ *) Available special lengths (connection type B):
4 = 3/8“ x 7/8“ 3, 5, 8, 10, 15 m [9.84, 16.40, 26.25, 32.80, 49.21‘]
order code expansion .XXXX = length in dm
c Interface / power supply
ex.: 8.5858.112B.2113.0030 (for cable length 3 m)
2 = CANopen DS301 V4.02 / 10 ... 30 V DC

1) Preferred type only in conjunction with flange type 2. 3) CAN parameters can also be factory pre-set.
2) Preferred type only in conjunction with flange type 1.
210 www.kuebler.com © Fritz Kübler GmbH, subject to errors and changes. 02/2015
