Absolute encoders - singleturn

Standard
optical Sendix 5858 / 5878 (shaft / hollow shaft) CANopen
www.HydroSanatSharif.com
Order code 8.5878 . X X 2 X . 21 1 X If for each parameter of an encoder the underlined preferred option is selected,
then the delivery time will be 10 working days for a maximum of 10 pieces.
Hollow shaft Type a b c d e f Qts. up to 50 pcs. of these types generally have a delivery time of 15 working days.
a Flange d Type of connection e Fieldbus profile 1)
1 = with spring element, long, IP65 removable bus terminal cover 21 = CANopen encoder profile DS406 V3.2
2 = with spring element, long, IP67 1 = radial cable gland
3 = with stator coupling, IP65 ø 65 mm [2.56“] 2 = 2 x M12 connector f Options (service)
4 = with stator coupling, IP67 ø 65 mm [2.56“] Fixed connection without bus terminal cover 2 = no options
5 = with stator coupling, IP65 ø 63 mm [2.48“] A = radial cable, 2 m [6.56‘] PVC 3 = SET button
6 = with stator coupling, IP67 ø 63 mm [2.48“] B = radial cable, special length PVC *)
E = 1 x radial M12 connector, 5-pin Optional on request
b Blind hollow shaft F = 2 x radial M12 connector, 5-pin - Ex 2/22
3 = ø 10 mm [0.39“] I = 1 x radial M23 connector, 12-pin - surface protection
4 = ø 12 mm [0.47“] J = 2 x radial M23 connector, 12-pin salt spray tested
5 = ø 14 mm [0.55“] *) Available special lengths (connection type B):
6 = ø 15 mm [0.59“] 3, 5, 8, 10, 15 m [9.84, 16.40, 26.25, 32.80, 49.21‘]
8 = ø 3/8“ order code expansion .XXXX = length in dm Absolute encoders
9 = ø 1/2“ ex.: 8.5878.542B.2113.0030 (for cable length 3 m) singleturn
c Interface / power supply
2 = CANopen DS301 V4.02 / 10 ... 30 V DC

Mounting accessory for shaft encoders Order no.
Coupling bellows coupling ø 19 mm [0.75“] for shaft 6 mm [0.24“] 8.0000.1102.0606
bellows coupling ø 19 mm [0.75“] for shaft 10 mm [0.39“] 8.0000.1102.1010

Mounting accessory for hollow shaft encoders Order no.
Cylindrical pin, long with fixing thread 8.0010.4700.0000

6: > @ P
for torque stops

0 5

Connection technology Order no.
Connector, self-assembly (straight) coupling M12 for Bus in 8.0000.5116.0000
connector M12 for Bus out 8.0000.5111.0000
Cordset, pre-assembled M12, for Bus in, 6 m [19.68‘] PVC cable 05.00.6091.A211.006M
M12, for Bus out, 6 m [19.68‘] PVC cable 05.00.6091.A411.006M
Further accessories can be found in the accessories section or in the accessories area of our website at: www.kuebler.com/accessories.
Additional connectors can be found in the connection technology section or in the connection technology area of our website at: www.kuebler.com/connection_technology.

Technical data

Mechanical characteristics
Maximum speed Protection acc. to EN 60529
-1
-1
IP65 up to 70°C [158°F] 9000 min , 7000 min (continuous) housing side IP67
IP65 up to Tmax 7000 min , 4000 min (continuous) shaft side IP65, opt. IP67
-1
-1
-1
-1
IP67 up to 70°C [158°F] 8000 min , 6000 min (continuous) Working temperature range -40°C ... +80°C [-40°F ... +176°F] 2)
IP67 up to Tmax 6000 min , 3000 min (continuous)
-1
-1
Material shaft/hollow shaft stainless steel
Starting torque - at 20°C [68°F] IP65 < 0.01 Nm flange aluminium
IP67 < 0.05 Nm housing zinc die-cast
Mass moment of inertia cable PVC
2
shaft version 3.0 x 10 kgm Shock resistance acc. to EN 60068-2-27 2500 m/s , 6 ms
-6
2
-6
hollow shaft version 6.0 x 10 kgm 2
2
Vibration resistance acc. to EN 60068-2-6 100 m/s , 55 ... 2000 Hz
Load capacity of shaft radial 80 N
axial 40 N
Weight with bus terminal cover approx. 0.53 kg [18.69 oz]
with fixed connection approx. 0.50 kg [17.64 oz]
1) CAN parameters can also be factory pre-set.
2) Cable version: -30°C ... +75°C [-22°F ... +167°F].
© Fritz Kübler GmbH, subject to errors and changes. 02/2015 www.kuebler.com 211
