Page 86 - Keubler Motion Sensors

Incremental encoders

Standard
sine wave output, highly interpolable, optical Sendix 5814 / 5834 (shaft / hollow shaft) SinCos
www.HydroSanatSharif.com

The incremental encoders Sendix 5814 and 5834 with SinCos
interface are particularly suited for applications in the field of
drive technology.
Thanks to their high signal quality, they are optimally suited for
further interpolation.

RoHS
2/22

-40°... +90°C IP
Safety-Lock TM High rotational Temperature High protection High shaft load Shock / vibration Magnetic field Reverse polarity SinCos Optical sensor Surface protection
speed range level capacity resistant proof protection salt spray-tested
optional
Powerful Flexible
• With incremental SinCos tracks. • Shaft and hollow shaft versions.
• Very high signal quality. • Cable and connector variants.
• Suited for motor feedback applications. • Various mounting options available.

Order code 8.5814 . 1 2 X X . XXXX If for each parameter of an encoder the underlined preferred option is selected,
then the delivery time will be 10 working days for a maximum of 10 pieces.
Shaft version Type a b c d e Qts. up to 50 pcs. of these types generally have a delivery time of 15 working days.
a Flange d Type of connection e Pulse rate
1 = clamping flange, IP65, ø 58 mm [2.28“] 1 = axial cable, 1 m [3.28‘] PVC 1024, 2048
A = axial cable, special length PVC *)
b Shaft (ø x L) 2 = radial cable, 1 m [3.28‘] PVC Optional on request
2 = 10 x 20 mm [0.39 x 0.79“], with flat B = radial cable, special length PVC *) - Ex 2/22
5 = axial M12 connector, 8 pin - surface protection salt spray tested
c Output circuit / power supply 6 = radial M12 connector, 8 pin
1 = SinCos / 5 V DC *) Available special lengths (connection types A, B):
2 = SinCos / 10 ... 30 V DC 2, 3, 5, 8, 10, 15 m [6.56, 9.84, 16.40, 26.25, 32.80, 49.21‘]
order code expansion .XXXX = length in dm
ex.: 8.5814.122A.2048.0030 (for cable length 3 m)

Order code 8.5834 . X X X X . XXXX If for each parameter of an encoder the underlined preferred option is selected,
then the delivery time will be 10 working days for a maximum of 10 pieces.
Hollow shaft Type a b c d e Qts. up to 50 pcs. of these types generally have a delivery time of 15 working days.
a Flange d Type of connection e Pulse rate
1 = with spring element, long, IP65 2 = radial cable, 1 m [3.28‘] PVC 1024, 2048
5 = with stator coupling, IP65, ø 63 mm [2.48“] B = radial cable, special length PVC *)
E = tangential cable, 1 m [3.28‘] PVC Optional on request
b Hollow shaft F = tangential cable, special length PVC *) - Ex 2/22
3 = ø 10 mm [0.39“] 6 = radial M12 connector, 8 pin - surface protection salt spray tested
K = ø 10 mm [0.39“], tapered shaft
4 = ø 12 mm [0.47“] *) Available special lengths (connection types B, F):
5 = ø 14 mm [0.55“] 2, 3, 5, 8, 10, 15 m [6.56, 9.84, 16.40, 26.25, 32.80, 49.21‘]
6 = ø 15 mm [0.59“] order code expansion .XXXX = length in dm
8 = ø 3/8“ ex.: 8.5834.142B.2048.0030 (for cable length 3 m)
9 = ø 1/2“

c Output circuit / power supply
1 = SinCos / 5 V DC
2 = SinCos / 10 ... 30 V DC

84 www.kuebler.com © Fritz Kübler GmbH, subject to errors and changes. 02/2015
