Incremental encoders

Compact
optical Sendix Base KIS40 / KIH40 (shaft / hollow shaft) Push-Pull / RS422 / open collector
www.HydroSanatSharif.com
Dimensions shaft version
Dimensions in mm [inch]

Clamping-synchro flange, ø 40 [1.57] 12 [0.47] 8.8[0.34] 120°
Flange type 1 90°
1 3 x M3, 4 [0.16] deep
2 4 x M3, 4 [0.16] deep 0.79] 1
40 [1.57] 36 [1.42] f8 h7 D 30 [1.18] 26 [1.02]

20
29[1.14]

2
2.1 [0.08]
2.2 [0.09] 45°
3 [0.12]
31.7 [1.25]
40.5 [1.59]
D = ø 6 [0.24]
ø 1/4“

Dimensions hollow shaft version
Dimensions in mm [inch]
3.9 [0.15] 14[0.55]
Flange with spring element, long
2.5 [0.1] 4[0.16]
2.4 [0.09]
Flange type 2

40 [1.57] 18 [0.71] D H7 30.7 [1.2] 35[1.37]

29[1.14]
M2.5, 4[0.16]deep
5.5 [0.22]
18 [0.71]
29.7 [1.17]
D = ø 8 [0.31] 44 [1.73] 8.8 [0.34]
ø 1/4“

Flange with stator coupling, ø 46 [1.81]
Flange type 5 53.6 [2.11]
6.8 [0.27] 46 [1.81]
Shaft: minimum insertion 1.3 [0.05]
depth 1.5 x D

40 [1.57] 39.6 [1.56] 18 [0.71] D H7

R1.60 29 [1.14]

5.3 [0.21]
12.4 [0.49]
18 [0.71]
D = ø 8 [0.31] 29.7 [1.17]
ø 1/4“
45.6 [1.79] 8.8 [0.31]
