Linear measuring technology

Length measuring kits
measuring wheels Various wheel coatings
www.HydroSanatSharif.com
a
Measuring wheels for measuring the length of products in move-
Diamond knurl 217 / 517
ment, e.g. in the paper, metal, textile, wood or plastic industry.
Tufted rubber 267 / 567
Various tyres to meet the requirements of the various surfaces of
Plastic corrugated 297 / 597 the product to be measured – various diameters, designed for use
with Kübler encoders, available for metric and imperial systems.
Plastic smooth 247 / 547

Selection of the measuring wheel profile according to the surface of the measured material

Surface of the measured material Recommended profile no.
Cardboard 1, 2, 3, 4, 5
Wood 1, 2, 3, 4, 5 Please note:
Textile 1, 2, 3, 4
If a measuring wheel is mounted directly on the shaft of a rotary enco-
Plastic (e.g. PVC, PE, ...) 2, 3, 4, 5 der, the pressure force between the measuring wheel and measured
Paper 2, 3, 4, 5 material should not exceed the radial shaft load listed in the data sheet
of the encoder.
Wire, greased metals, steel profiles, leather 2
In addition, the measuring wheels can only be used for in-house
Carpet, cables, nonwoven 3
purposes which are not subject to the stipulations of the German
Greased metals, glass, floor coverings 4 calibration code.
Linear measuring
Painted surfaces 2, 4
Rubber, soft plastic 1 technology

Order code 8.0000 . 3 XXX . 00 XX
Measuring wheels a b

Measuring wheel Profile Coating Coating Wheel Weight Standard Material Working
Circumference / ø / width measuring hard- no. bore b 1) of wheel temperature
wheels ness a body
(s.o.) Shore A
1 diamond knurl (aluminium) 217 60 g [2.12 oz]
0.2 m / ø 63.7 mm / 12 mm 2 plastic (polyurethane) smooth 90 247 60 g [2.12 oz] 06 = 6 mm [0.24“] -30°C ... +80°C
[7.87“ / ø 2.51“ / 0.47“] 3 tufted rubber (polyurethane) 60 267 60 g [2.12 oz] 10 = 10 mm [0.39“] aluminium [-22°F ... +176°F]
4 plastic (polyurethane) corrugated 90 297 60 g [2.12 oz]
1 diamond knurl (aluminium) 517 775 g [27.34 oz]
0.5 m / ø 159.2 mm / 25 mm 2 plastic (polyurethane) smooth 90 547 700 g [24.69 oz] -30°C ... +80°C
[19.69“ / ø 6.27 / 0.98“] 3 tufted rubber (polyurethane) 60 567 700 g [24.69 oz] 10 = 10 mm [0.39“] aluminium [-22°F ... +176°F]
4 plastic (polyurethane) corrugated 90 597 700 g [24.69 oz]
12” / ø 3.82“ / 0.38“ -30°C ... +80°C
5 natural rubber (NR) smooth 751 100 g [3.53 oz] 10 = 10 mm [0.39“] aluminium
[-22°F ... +176°F]

1) Other bore diameters on request
