Basics
Connection technology
The idea behind our connection
www.HydroSanatSharif.com
technology system
Introduction
Material information - cables
Material information - connectors Two material groups are used for the connectors described in the catalogue:
© Fritz Kübler GmbH, subject to errors and changes. 02/2015
Introduction / Cables and connectors
Connection technology from Kübler = system safety!
All the products in the connection technology
section have been tested and approved with the
relevant compatible Kübler sensors. Product overview
They ensure the full functionality and high signal Basics
quality of our sensors.
Your benefit:
• Elimination of connection errors
– no laborious fault finding
• Optimal shielding
– avoids EMC problems
• Shorter installation times
– saves time, cuts costs
• No time-consuming search for the right
connector or cable
– saves time, eliminates errors
All products of chapter connection technology have Your advantage:
been tested and released in relation with the
corresponding compatible Kübler sensors. • Prevents from misconnections
- No time-consuming search for errors
They ensure the full functionality and high signal • Optimal shielding
quality of our sensors - this guarantee is supported - Prevents from EMC problems
by our competent customer service.
• Shorter mounting times
- Time- and thus cost-savings
• No time-consuming search for the suitable
connector or cable
- Time-savings and error prevention
PVC PUR
• Suitable for average mechanical stresses in the • Flexible, PVC, silicone and halogen-free control
area of packaging machines and assembly and cable with PUR cable jacket and polypropylene
production lines. wire insulation.
• Good resistance against acids and alkalis and • The cable is oil-resistant and non-flammable
thus predestined for use in the food and beverage according to VDE 0472, and it is resistant to
industry. chemicals, hydrolysis and microbes.
• Limited friction resistance and partial resistance • Temperature resistance from -30°C to + 90°C.
to oils and chemicals. • Use is possible in trailing cable carriers with a
bending radius equal at least to 10 x D.
• Thanks to its resistance to welding sparks, this
cable is very well adapted for flexible use in the
area of robotics, machine tools and metal cutting
production.
Metals for contacts and housings Plastics for insulator and housing
• Contacts: • Contact carrier:
metal, CuZn, gilded plastic, TPU, black
• Connecting nut /compression screw: • Body:
metal, CuZn, nickel-plated plastic, TPU, black
• Seal:
plastic, fluorine rubber (FKM/FPM) FPM/FKM or
nitrile-butadiene rubber (NBR)
