Basics
Optical fibre signal transmission General information
Description The system is made up of an optical fibre transmitter Main advantages of an optical fibre transmission:
www.HydroSanatSharif.com
and an optical fibre receiver. • Insensitivity to electromagnetic interferences and
The optical fibre transmitter converts the electrical to leakage effects between lines routed parallel
signals of an encoder into optical fibre signals. • Significantly higher transmission speeds Product overview
A simple glass fibre allows reliable transmission up
to distances of 2000 m. • The optical fibre cable can be routed through Basics
explosive atmospheres
The receiver module converts the optical signals
back into electrical signals. • Cost and weight savings thanks to reduced
cabling work, especially for important cable
The modules are available in various level and lengths
power supply voltage variants.
Mounting of optical fibre modules The optical fibre modules can be mounted directly on
a TS35 DIN rail (top-hat rail) according to EN 50022.
The installation width for every module is only 19 mm.
Laying and connection Laying the cable is generally easy. When connecting the cable, make sure that the
of glass fibre cables Care must nevertheless be taken to make sure bayonet catch is locked and remove the dust
protection caps only just before connecting the
that the bending radius does not become smaller cable.
than 30 mm for static laying and 60 mm for dynamic
laying.
Glass fibre cables The modules can be connected together using Kübler offers finished confectioned patch cables
50/125 µm or 62.5/125 µm multimode glass fibre adapted to the optical fibre modules as accessories.
cables with ST/PC type connectors with bayonet
catch. Single-mode Simplex patch cables are not They ensure the full functionality and high signal
suitable. quality of our sensors.
