Basics

Encoders Installing encoders

Particular shaft loading due to toothed- Measuring wheels, toothed wheels or gear pulleys, If these load values may be exceeded in a particular
www.HydroSanatSharif.com
wheels, gear-pulleys and similar elements which are mounted directly on the encoder shaft, application, then the encoder shaft must be isolated
exert radial forces on the latter, dependent on from the radial load by interposing an appropriate
prestressing and angular acceleration. shaft with its own bearings that can absorb the Product overview
Kübler encoders are designed so that they can forces.
absorb these forces to a great extent. The maximum Kübler offers suitable bearing blocks and bearing Basics
permissible load capacity of the shaft is shown in the boxes for this purpose (please refer to the ‚Acces-
technical data for the encoder. sories‘ section in the catalogue).

Isolation insert Thermal and electrical isolation of the encoders.
Isolation inserts prevent currents from passing
through the encoder bearings. These currents can
occur when using inverter controlled threephase
or AC vector motors and considerably shorten the
service life of the encoder bearings. In addition the
encoder is thermally isolated as the plastic does not
transfer the heat to the encoder.

© Fritz Kübler GmbH, subject to errors and changes. 02/2015 www.kuebler.com 33
