Basics




             Encoders                          Installing encoders


            Mounting examples for shaft encoders   Fastening eccentrics + coupling
        www.HydroSanatSharif.com
            with synchronous flange            (to reduce shaft overload)
                                                                                                                    Product overview  Basics







                                              Assembly bell, fastening eccentrics + coupling
                                              (to prevent shaft overload and to isolate the encoder
                                              thermally and electrically)









            Mounting examples for shaft encoders    Angular bracket + coupling
            with clamping bracket             (to reduce shaft overload)










                                              Clamping device + coupling
                                              (to reduce shaft overload)
