Absolute encoders - singleturn




          Standard
          optical                         Sendix 5853 / 5873 (shaft / hollow shaft)  SSI / BiSS
        www.HydroSanatSharif.com
         Technical data
         Mechanical characteristics                          BiSS interface
         Maximum speed shaft version                         Resolution               10 ... 14 bit, 17 bit and 21bit
                                        -1
                                                -1
                    IP65 up to 70°C [158°F]   12000 min , 10000 min  (continuous)   Code        binary
                                              -1
                                        -1
                        IP65 up to Tmax   8000 min , 5000 min  (continuous)
                                        -1
                    IP67 up to 70°C [158°F]   11000 min , 9000 min  (continuous)   Clock rate        50 kHz ... 10 MHz
                                               -1
                                        -1
                                              -1
                        IP67 up to Tmax   8000 min , 5000 min  (continuous)  Max. update rate        < 10 µs, depends on the clock rate
                                                                                      and the data length
         Maximum speed hollow shaft version
                                              -1
                                        -1
                    IP65 up to 70°C [158°F]   9000 min , 6000 min  (continuous)   Data refresh rate        ) 1 µs
                                              -1
                                        -1
                        IP65 up to Tmax   6000 min , 3000 min  (continuous)   Note:   –  Bidirectional, factory programmable parameters are:
                                              -1
                                        -1
                    IP67 up to 70°C [158°F]   8000 min , 4000 min  (continuous)           resolution, code,  direction, alarms and warnings
                        IP67 up to Tmax   4000 min , 2000 min  (continuous)        –  CRC data verification
                                              -1
                                        -1
         Starting torque      IP65   < 0.01 Nm
         at 20°C [68°F]       IP67   < 0.05 Nm
         Mass moment of inertia                              SET input or SET button
                                       -6
                         shaft version   3.0 x 10  kgm   2        Input               active HIGH
                     hollow shaft version   6.0 x 10  kgm 2
                                       -6
                                                             Input type               comparator
         Load capacity of shaft       radial   80 N
                             axial   40 N                    Signal level        HIGH  min: 60 % of +V (power supply)
                                                                                      max: +V
         Weight                    approx. 0.35 kg [12.35 oz]
                                                                                 LOW  max: 25 % of +V (power supply)
         Protection      housing side   IP67                 Input current            < 0.5 mA
         acc. to EN 60529   shaft side   IP65, opt. IP67
                                                             Min. pulse duration (SET)       10 ms
         Working temperature range      -40°C ... +90°C [-40°F ... +194°F]  1)
                                                             Timeout after SET signal       14 ms
         Materials      shaft/hollow shaft   stainless steel
                             flange   aluminium               Response time (DIR input)       1 ms
                            housing   zinc die-cast          The encoder can be set to zero at any position by means of a HIGH signal on
                             cable   PVC                     the SET input or by pressing the optional SET button (with a pencil, ball-point
         Shock resistance acc. EN 60068-2-27     2500 m/s , 6 ms  pen or similar).
                                        2
                                                             Other preset values can be factory-programmed. The SET input has a signal
         Vibration resistance acc. EN 60068-2-6  100 m/s , 55 ... 2000 Hz
                                       2
                                                             processing time of approx. 1 ms. Once the SET function has been triggered,
                                                             the encoder requires an internal processing time of approx. 15 ms before the
         Electrical characteristics                          new position data can be read. During this time the status output is at LOW.
         Power supply              5 V DC (+5 %) or 10 ... 30 V DC
         Current consumption (no load)   5 V DC  max. 70 mA             Option incremental outputs (A/B), 2048 ppr
                         10 ... 30 V DC  max. 45 mA
                                                                               SinCos         RS422 TTL compatible
         Reverse polarity protection      yes
         of the power supply                                 Max. frequency -3dB   400 kHz    400 kHz
                                                             Signal level      1 Vpp (±20 %)   HIGH:    min. 2.5 V
                                     2)
         Short circuit proof outputs     yes
                                                                                              LOW:   max. 0.5 V
         UL approval               file 224618
                                                             Short circuit proof   yes        yes
         CE compliant acc. to       EMC guideline 2004/108/EC
                                   RoHS guideline 2011/65/EU
                                                             Status output and LED
         SSI interface                                       Output driver            open collector, internal pull up
                                                                                      resistor 22 kOhm
         Output driver             RS485 transceiver type
                                                             Permissible load         max. 20 mA
         Permissible load / channel     max. +/- 20 mA
                                                             Signal level        HIGH  +V
         Signal level         HIGH  typ. 3.8 V
                    LOW at I Load  = 20 mA   typ. 1.3 V                          LOW  < 1 V
                                                             Active                   LOW
         Resolution                10 ... 14 bit and 17 bit
                                                             The optional LED (red) and the status output serve to display various alarm or error
         Code                      binary or gray
                                                             messages. In normal operation the LED is OFF and the status output is HIGH (Open
         SSI clock rate            50 kHz ... 2 MHz          Collector with int. pull-up 22 kOhm).
         Monoflop time              ) 15 µs                   An active status output (LOW) displays:
         Note: If the clock starts cycling within the monoflop time, a second data transfer       - Sensor error, singleturn or multiturn (soiling, glass breakage etc.)
         starts with the same data. If the clock starts cycling after the monoflop time, the      - LED fault (failure or ageing)
         data transfer starts with the new values. The update rate is dependent on the      - over- or under-temperature
         clock speed, data length and monoflop-time.          In the SSI mode, the fault indication can only be reset by switching off the
         Data refresh rate   resolution ) 14 bit  ) 1 µs          power supply to the device.
                      resolution * 15 bit  4 µs
         1)   Cable version: -30°C ... +75°C [-22°F ... +167°F].
         2)  Short circuit to 0 V or to output, one channel at a time,
            power supply correctly applied.
