Absolute encoders - singleturn

Standard
optical Sendix 5853 / 5873 (shaft / hollow shaft) SSI / BiSS
www.HydroSanatSharif.com
Dimensions hollow shaft version
Dimensions in mm [inch]

Flange with stator coupling, ø 63 [2.48]
Flange type 5 and 6
Pitch circle diameter for fixing screws 63 [2.48]
(drawing with M23 connector)

1 Fixing screws DIN 912 M3 x 8
(washer included in delivery) ' +
2 Recommended torque for the
clamping ring 0.6 Nm > @ ƒ

PD[

Flange with stator coupling, mounting without screws
Flange type E and F
(with tapered shaft K and tangential cable)

1 Status LED
2 SET button

0

Flange with stator coupling, ø 72 [2.83]
Flange type G “ > @
(with tapered shaft K and tangential cable)

1 Status LED
2 SET Button

0
