Product overview
www.HydroSanatSharif.com
Connection technology PVC cable PUR cable TPE cable Optical fibre Straight connector Right angle connector for incremental encoders for SSI / BiSS encoders for fieldbus for analogue interfaces Product overview
Cordsets, pre-assembled Page Basics
with M12 connector • • – – • • • • • • 457
with M23 connector • • • – • – • • – • 469
Simplex patch cable – – – • • – • • – – 139
optical fibre 483
with Sub-D connector – • – – – • – – • – 474
Transmission distance in m Input frequency in kHz Temperature in °C [°F] Power / Current in VDC Power consumption in W
Optical fibre transmission Interface
modules (LWL) Page
Optical fibre module, RS422 -10 ... +60 5
incremental HTL 1.000 400 [-14 ... +140] 10 ... 30 2 483
LWL
Optical fibre module, -10 ... +70 5
absolute SSI 2.000 1.000 [-14 ... +158] 10 ... 30 1 485
LWL.A
© Fritz Kübler GmbH, subject to errors and changes. 02/2015 www.kuebler.com 17
