Page 18 - Keubler Motion Sensors

Product overview

www.HydroSanatSharif.com
Connection technology Cross section in mm 2 Cable diameter in mm for incremental encoders for absolute encoders
Cable, unprepared, cut to PVC cable PUR cable TPE cable
length Page

5 x 0.14 [AWG25] approx. 4.7
5 core + shield • • – • – 448
5 x 0.75 [AWG18] approx. 7.5

8 core + shield – • – 8 x 0.14 [AWG25] approx. 5.5 – • 448

10 core + shield – • – 4 x 2 x 0.25 [AWG23] + 2 x 1 [AWG17] approx. 7.9 • • 448

10 x 0.14 [AWG25] + 2 x 0.5 [AWG20] approx. 6.9
12 x 0.14 [AWG25] approx. 6.7
12 core + shield • • • 6 x 2 x 0.14 [AWG25] approx. 7.5 • • 449
5 x 2 x 0.14 [AWG25] + 2 x 0.5 [AWG20] approx. 8.5
6 x 2 x 0.14 [AWG25] approx. 7.3

18 core + shield • – – 18 x 0.14 [AWG25] approx. 7.8 – • 449

PROFIBUS DP 2 x 0.34 [AWG25] approx. 7.6
DeviceNet 2 x 0.52 [AWG20] + 2 x 1.04 [AWG17] approx. 8.4
CANopen • • – 3 x 2 x 0.25 [AWG23] approx. 6.2 • • 450
EtherCAT / PROFINET IO 2 x 2 x 0.34 [AWG22] approx. 4.8
EtherNet IP

Connection technology Cable diameter Ø in mm Straight connector Right angle connector Wall/panel lead-through

Connection technology Nº of pins Housing for fieldbus
Connectors, self-assembly Page

M12 4/5/8/12 Metal Screw terminals 6 - 8 • • • • 451

M23 12/17 Metal Solder pins 5.5 - 10.5 • – • – 467

MIL 7/10 Metal Solder pins 5 - 8 • – – – 473

16 www.kuebler.com © Fritz Kübler GmbH, subject to errors and changes. 02/2015
