Product overview

Ø Dimensions in mm [inch] Magnetic (Accuracy ±1°) Optical (Accuracy ≤ ±0.015°) Resolution max. in bit ST+MT Additional incremental track Speed max. in min -1 Temperature range in °C [°F] Power supply in V DC RoHS compliant Product overview
www.HydroSanatSharif.com

Absolute encoders SSI interface BiSS interface Protection max. Type of connection Approvals Basics
Multiturn RoHS Page

Standard, optical
mechanical multiturn 70 • 17 +12 • • – 6.000 -40 ... +60 IP67 cable 10 ... 30 • 348
ATEX / IECEx – zone 1 / 21 [2.76] [-40 ... +140]
Sendix 7063 (shaft)

Standard, optical
mechanical multiturn 70 -40 ... +60
ATEX / IECEx – zone 1 / 21 [2.76] • 17 +12 • • SinCos 6.000 [-40 ... +140] IP67 cable 10 ... 30 • 351
SIL2 / PLd
Sendix SIL 7063FS2 (shaft)
Standard, optical
mechanical multiturn 70 -40 ... +60
ATEX / IECEx – zone 1 / 21 [2.76] • 17 +12 • • SinCos 6.000 [-40 ... +140] IP67 cable 10 ... 30 • 355
SIL3 / PLe
Sendix SIL 7063FS3 (shaft)

Standard, optical
mechanical multiturn 70 • 17 +12 • • – 6.000 -40 ... +60 IP67 cable 10 ... 30 • 365
ATEX / IECEx – mining [2.76] [-40 ... +140]
Sendix 7163 (shaft)

Large hollow shaft,
optical / magnetic, 90 -20 ... +70 cable 4.75...30
• 13 +12 • – – 6.000 IP65 • 381
programmable [3.54] [-4 ... +158] M23 5 ... 30
9081 (Large hollow shaft)
