Product overview

Ø Dimensions in mm [inch] Magnetic (Accuracy ±1°) Optical (Accuracy ≤ ±0.015°) Resolution max. in bit Analogue / RS485 interface Additional incremental track Speed max. in min -1 Temperature range in °C [°F] Power supply in V DC RoHS compliant Product overview
www.HydroSanatSharif.com

Absolute encoders SSI interface BiSS interface Paralell interface Protection max. Type of connection Approvals Basics
Singleturn RoHS Page

Standard, optical
70 -40 ... +60
ATEX / IECEx – zone 1 / 21 – • 17 • • – – – 6.000 IP67 cable 10 ... 30 • 232
[2.76] [-40 ... +140]
Sendix 7053 (shaft)
Standard, optical
ATEX / IECEx – zone 1 / 21 70 – • 17 • • – – SinCos 6.000 -40 ... +60 IP67 cable 10 ... 30 • 235
SIL2 / PLd [2.76] [-40 ... +140]
Sendix SIL 7053FS2 (shaft)

Standard, optical
ATEX / IECEx – zone 1 / 21 70 – • 17 • • – – SinCos 6.000 -40 ... +60 IP67 cable 10 ... 30 • 239
SIL3 / PLe [2.76] [-40 ... +140]
Sendix SIL 7053FS3 (shaft)

Standard, optical
70 -40 ... +60
ATEX / IECEx – mining – • 17 • • – – – 6.000 IP67 cable 10 ... 30 • 249
[2.76] [-40 ... +140]
Sendix 7153 (shaft)

Ø Dimensions in mm [inch] Magnetic (Accuracy ±1°) Optical (Accuracy ≤ ±0.015°) Temperature range in °C [°F] RoHS compliant

Absolute encoders Resolution max. in bit Speed max. in min -1 Type of connection Power supply in V DC
Singleturn CANopen SAE J1939 PROFIBUS DP EtherCAT PROFINET IO Protection max. Approvals
Fieldbus RoHS Page

Compact, magnetic 36 -40 ... +85 cable
Sendix M3658 (shaft) [1.43] • – • • – – – 14 6.000 [-40 ... +185] IP69k M12 8 ... 30 • 2/22 160
Sendix M3678 (hollow shaft)

Compact, optical 36 -40 ... +85
Sendix F3658 (shaft) [1.43] – • • – – – – 16 12.000 [-40 ... +185] IP67 cable 10 ... 30 • 174
Sendix F3678 (hollow shaft)

Standard, optical cable
58 -40 ... +80
Sendix 5858 (shaft) – • • – • • • 16 9.000 IP67 M12 10 ... 30 • 205
[2.28] [-40... +176]
Sendix 5878 (hollow shaft) M23 2/22
Standard, optical
70 -40 ... +60
ATEX / IECEx – zone 1 / 21 – • • – • – – 16 6.000 IP67 cable 10 ... 30 • 243
[2.76] [-40 ... +140]
Sendix 7058 (shaft)
Standard, optical 70 -40 ... +60
ATEX / IECEx – mining [2.76] – • • – • – – 16 6.000 [-40 ... +140] IP67 cable 10 ... 30 • 252
Sendix 7158 (shaft)
