Product overview

Ø Dimensions in mm [inch] Magnetic (Accuracy ±1°) Optical (Accuracy ≤ ±0.015°) Resolution max. in bit Analogue / RS485 interface Additional incremental track Speed max. in min -1 Temperature range in °C [°F] Power supply in V DC RoHS compliant
www.HydroSanatSharif.com

Absolute encoders SSI interface BiSS interface Paralell interface Protection max. Type of connection Approvals
Singleturn RoHS Page

Miniature, magnetic 24 -20 ... +85
2450 (shaft) [0.94] • – 12 • – – – – 12.000 [-4 ... +185] IP67 cable 5 • – 152
2470 (hollow shaft)

Compact, magnetic
analogue 36 • – 12 – – 4 ... 20 mA – – 6.000 -40 ... +85 IP69k cable 10 ... 30 • 155
Sendix 3651 (shaft) [1.43] 0 ... 10 V [-40 ... +185] M12 15 ... 30
Sendix 3671 (hollow shaft) 2/22

Compact, optical 36 Sin Cos -40 ... +90 cable 5
Sendix F3653 (shaft) [1.43] – • 17 • • – – RS422 12.000 [-40 ... +194] IP67 M12 10 ... 30 • 168
Sendix F3673 (hollow shaft)

Standard, optical
paralell / analogue 58 – • 13 – – 4 ... 20 mA • – 12.000 -20 ... +85 IP66 cable 5 • 178
5850 (shaft) [2.28] [-4 ... +185] M23 10 ... 30
5870 (hollow shaft)

Standard, optical
paralell, highspeed 58 -20 ... +85 cable 5
– • 14 – – – • – 12.000 IP66 • 183
5852 (shaft) [2.28] [-4 ... +185] M23 10 ... 30
5872 (hollow shaft)

Standard, optical 58 Sin Cos -40 ... +90 cable 5
Sendix 5853 (shaft) [2.28] – • 17 • • – – RS422 12.000 [-40 ... +194] IP67 M12 10 ... 30 • 186
Sendix 5873 (hollow shaft) M23 2/22

Standard, optical
SIL2 / PLd 58 9.000/ -40 ... +90 cable 5
– • 17 • • – – Sin Cos IP65 • 193
Sendix SIL 5853FS2 (shaft) [2.28] 12.000 [-40 ... +194] M23 10 ... 30 2/22
Sendix SIL 5873FS2 (Hollow s.)

Standard, optical
SIL3 / PLe 58 – • 17 • • – – Sin Cos 9.000/ -40 ... +90 IP65 cable 5 • 199
Sendix SIL 5853FS3 (shaft) [2.28] 12.000 [-40 ... +194] M23 10 ... 30 2/22
Sendix SIL 5873FS3 (hollow s.)

Standard, optical
stainless-steel 58 -20 ... +80 cable 5
– • 14 • – – • – 6.000 IP67 • 228
SSI / paralell [2.28] [-4 ... +176] M12 10 ... 30
5876 (hollow shaft) 2/22
