Incremental encoders

Large hollow shaft
robust, optical A02H (hollow shaft) Push-Pull / RS422 / SinCos
www.HydroSanatSharif.com

The Heavy Duty incremental encoder type A02H boasts a high
degree of ruggedness in a very compact design.

Its special construction makes it perfect for all applications in
very harsh environments.

RoHS
2/22 LETTER OF CONFORMITY NO. 74130

IP
High rotational High protection High shaft load Shock / vibration Magnetic field Optical sensor
speed level capacity resistant proof

Heavy Duty - robust Compact and versatile
• Special shaft connection with interlocked bearings. • Only 49 mm installation depth.
• Balanced stainless steel clamping ring. • With cable connections, M12, M23 or MIL connectors.
• Optional isolation inserts available to protect against shaft • With Push-Pull, RS422 or SinCos interface.
currents.

Order code 8.A02H . X X X X . XXXX
Hollow shaft Type a b c d e
a Flange c Output circuit / power supply e Pulse rate
1 = without mounting aid 1 = RS422 (with inverted signal) / 5 V DC 50, 360, 512, 600, 1000, 1024, 1500,
2 = with spring element, short 4 = RS422 (with inverted signal) / 10 ... 30 V DC 2000, 2048, 2500, 4096, 5000
3 = with spring element, long 2 = Push-pull (without inverted signal) / 10 ... 30 V DC (e.g. 360 pulses => 0360)
5 = with fastening arm, long 5 = Push-pull (with inverted signal) / 5 ... 30 V DC
3 = Push-pull (with inverted signal) / 10 ... 30 V DC SinCos version only available
6 = with fastening arm, short, 4.5“ 1) 8 = SinCos, 1 Vpp (with inverted signal) / 5 V DC with pulses * 1024
9 = SinCos, 1 Vpp (with inverted signal) / 10 ... 30 V DC
b Hollow shaft A = Push-pull (7272 compatible) / 5 ... 30 V DC Optional on request
C = ø 20 mm [0.79“] - other pulse rates on request
5 = ø 25 mm [0.98“] D = RS422 (with inverted signal) / 5 ... 30 V DC 1) - Ex 2/22
3 = ø 28 mm [1.10“]
A = ø 30 mm [1.18“] d Type of connection
2 = ø 38 mm [1.50“] 1 = radial cable, 1 m [3.28‘] PVC
B = ø 40 mm [1.57“] A = radial cable, special length PVC *)
1 = ø 42 mm [1.65“] 2 = radial M23 connector, 12-pin, without mating connector
4 = ø 1’’ E = radial M12 connector, 8-pin
E = ø 5/8“ 1) D = MIL connector, 10-pin 1)
N = ø 1 1/4“ 1) *) Available special lengths (connection type A):
2, 3, 5, 8, 10, 15 m [6.56, 9.84, 16.40, 26.25, 32.80, 49.21‘]
order code expansion .XXXX = length in dm
ex.: 8.A02H.111A.2048.0030 (for cable length 3 m)

1) US version
