Accessories

Fixing components for hollow shaft encoders For encoders up to ø 58 mm Details

www.HydroSanatSharif.com
Dimensions / Details Dimensions in mm [inch] Order no.

Stator coupling Scope of delivery: 8.0010.4048.00FS
! !
- Stator coupling
(stainless steel)
- 4 screws M3x6 mm
[M3 x 0.24“] for fixing
> @
" to the encoder "

ƒ Connection to application:
- 4 screws
(not supplied)

# Max. permissible shaft #
connection tolerances:
- Axial offset < ± 0,25 mm
- Radialversatz < ± 0,20 mm
- Winkelversatz < 1°
$ “ > @ $

% %
