Accessories

Fixing components for hollow shaft encoders For encoders up to ø 58 mm Details

www.HydroSanatSharif.com
Dimensions / Details Dimensions in mm [inch] Order no.
Stator coupling Scope of delivery: 8.0010.1602.0000
for side fixing onto the encoder - Stator coupling
flange (stainless steel)
- 4 screws M2 x 4 mm
for fixing to the encoder 5882
- 4 screws M2,5 x 6 mm
for fixing to the encoder
582X, 587X, 502X, 58x3, F58x3
Connection to application:
- 3 screws
(not supplied)

Stator coupling Scope of delivery: 8.0010.40L0.0000
for front fixing onto the encoder 1 8 - Stator coupling
flange (stainless steel)
4,3 - 2 screws for fixing to the
120° encoder
26 Connection to application:
R
R16
44 - 3 screws
18
(not supplied)

(3x)
+0,2 60° 120°
3,3 5 , 0
16 0± 0 , 5
42
65
74

Spring tether element Scope of delivery: 8.0010.40W0.0000
- Drahtfederelement
- 1 Schraube zur Befestigung
am Drehgeber
Connection to application:
- 1 screw
(not supplied)

Clamping ring for for hollow Accessories
Stainless steel, for high rotational encoder B D1 shaft ø
speeds
A 582X 6 [0.236] 29 [1.14] 10 [0.39] 8.0000.4V00.0000
1
6.2 [0.244] 30 [1.18] 12 [0.47] 8.0000.4W00.0000
5020 6.2 [0.244] 30 [1.18] 12 [0.47] 8.0010.4W01.0000

A
B D1
1 screw DIN 912 A2 M2.5,
max. tightening torque 0.45 Nm

© Fritz Kübler GmbH, subject to errors and changes. 02/2015 www.kuebler.com 495
