Accessories

Fixing components for hollow shaft encoders For encoders up to ø 58 mm Details

www.HydroSanatSharif.com
Dimensions / Details Order no.
Fastening arm, long 50 Scope of delivery: 8.0010.4R00.0000
- Fastening arm (stainless steel)
42
- 3 screws for fixing to the
35
encoder
Connection to application:
15,55 7,8 14,3 7,8
6,3 - 1 screw
(not supplied)
18

3,3
41,1
56
69,25
85
92,5
27,5
9,5 0,5 R2

R2

Stator coupling, double-winged Scope of delivery: 8.0010.4C00.0000
for front fixing onto the encoder - Stator coupling
flange (stainless steel)
- 2 screws for fixing to the
encoder
30° 29
Connection to application:
- 2 screws
(not supplied)
2 , 3
6 , 5
4 6 0± 3 ,
1 4 , 3

3,2
6 , 1

Stator coupling, double-winged Scope of delivery: 8.0010.4D00.0000
for side fixing onto the encoder 1 2 63 - Stator coupling
flange (stainless steel)
1 4 screws M2 x 4 [0.16]
for fixing to the encoder 5882
6,5 7 2 4 screws M2.5 x 6 [0.24]
9 for fixing to the encoders
582X, 587X, 502X
25∞ Connection to application:
- 2 socket head screws
M3 x 8 [0.32] with washer
3,2 (supplied)
