Inclinometers

Inclinometer
MEMS / capacitive IS60, 1-dimensional CANopen
www.HydroSanatSharif.com

With the IS60 inclinometer 1-dimensional inclinations in the
measuring range 360° can be measured.
The sensor has a standardised CANopen interface, which enables
easy configuration and start-up. All the parameters are stored in
the internal permanent memory.

RoHS

IP
High protection Shock / vibration Reverse polarity
level resistant protection

Robust and reliable User-friendly and accurate
• Protection rating IP68 / IP69k. • High resolution and accuracy.
• Robust plastic housing. • Programmable vibration suppression.
• High shock resistance. • High sampling rate and bandwidth.

Order code 8.IS60 . 1 4 5 2 3 Attention :
This is not a standard product. Delivery on request.
Inclinometer IS60 Type a b c d e Min. order quantity / frame order required.
a Measuring direction b Measuring range c Interface d Power supply e Type of connection
1 = 1-dimensional 4 = 360° 5 = CANopen 2 = 10 ... 30 V DC 3 = 2 x M12 connector

Connection technology Order no.
Connector, self-assembly (straight) M12 female connector with coupling, Bus in 05.B-8151-0/9
M12 male connector with external thread, Bus out 05.BS-8151-0/9
Cordset, pre-assembled M12 female connector with coupling, 6 m [19.69‘] PVC cable, Bus in 05.00.6021.2211.006M
M12 male connector with external thread, 6 m [19.69‘] PVC cable, Bus out 05.00.6021.2411.006M

Further accessories can be found in the accessories section or in the accessories area of our website at: www.kuebler.com/accessories
Additional connectors can be found in the connection technology section or in the connection technology area of our website at: www.kuebler.com/connection_technology
