Linear measuring technology
Draw wire mechanics Measuring length max. 2 m
with absolute encoder Draw wire encoder A41 Traverse speed max. 1 m/s
www.HydroSanatSharif.com
Guide pulley for draw wire encoder Order no.
Guide pulley Order code for the set: 8.0000.7000.0045
- Guide pulley (anodised aluminium)
- 2 x countersunk screws
for lateral fixing
- 2 x hexagonal screws
for fixing on a flat surface
Extension cable Steel wire 2 m [6.56‘] 8.0000.7000.0033
PD[ PD[ Steel wire 5 m [16.40‘] 8.0000.7000.0034
Steel wire 10 m [32.81‘] 8.0000.7000.0035
0 0
Paraleine 2 m [6.56‘] 8.0000.7000.0032
/ /
Technical data
Mechanical characteristics (draw wire mechanics) Electrical characteristics (encoder)
Measuring range up to 2000 mm The electrical characteristics can be found in the data sheets of the encoders.
Traversing speed max. 1000 mm/s
Working temperature -10°C ... +80°C [+14°F ... +176°F]
Weight approx. 200 g [7.06 oz]
Required force * 2 N (on wire)
Linearity ±0.35 %
for the whole measuring range
Repetition accuracy ±0.15 mm per direction of travel
Material housing zinc die-cast
wire stainless steel ø 0.45 mm
! !
Dimensions
Dimensions in mm [inch]
PLQ
" 0 "
# #
$ $
% %
