Page 155 - Keubler Motion Sensors

Absolute encoders - singleturn

Miniature
magnetic 2450 / 2470 (shaft / hollow shaft) SSI
www.HydroSanatSharif.com
Technical data
Mechanical characteristics Electrical characteristics SSI interface
Maximum speed 12000 min -1 Sensor
-6
Mass moment of inertia approx. 0.1 x 10 kgm 2 Power supply 5 (+0,4) V DC 1)
Starting torque - at 20°C [68°F] < 0.01 Nm Power consumption (no load) < 40 mA
Shaft load capacity radial 10 N Reverse polarity protection of the yes
axial 20 N power supply
Weight approx. 0.06 kg [2.11 oz] Measuring range 360°
Protection housing side IP65 (IP67 on request) Resolution 12 bit
acc. to EN 60529 flange side IP50 (IP67 on request) Code gray
Working temperature range -20°C ... +85°C [-4°F ... +185°F] Linearity, 25°C [77°F] < 1.5°
Material shaft / hollow shaft stainless steel Repeat accuracy ) 0.4°
clamping ring MS58 Absolute encoders
Data refresh rate typ. 100 µs singleturn
2
Shock resistance acc. to EN 60068-2-27 1000 m/s , 6 ms
CE compliant acc. to EMC guideline 2004/108/EC
2
Vibration resistance acc. to EN 60068-2-6 100 m/s , 55 ... 2000 Hz RoHS guideline 2011/65/EU
SSI interface
SSI clock speed 100 kHz ... 750 kHz
Output driver RS485
Monoflop time typ. / max. 16 µs / 20 µs
Short circuit proof output yes 2)
Permissible load / channel typ. 60 Ohm (acc. to RS485)

Terminal assignment
Interface Type of connection Cable (isolate unused wires individually before initial start-up)
Signal: 0 V +V C+ C- D+ D-
2 1, 2, A, B
Cable colour: WH BN GN YE GY PK
+V : Encoder power supply +V DC
0 V : Encoder power supply ground GND (0 V)
C+, C- : Clock signal
D+, D- : Data signal

1) The power supply at the encoder input must not be less than 4.75 V DC (5 V DC - 5 %).
2) Short circuit to 0 V or to output, only one channel at a time, power supply correctly applied.
© Fritz Kübler GmbH, subject to errors and changes. 02/2015 www.kuebler.com 153
