Incremental encoders

www.HydroSanatSharif.com
Series Type Output circuit Page
Miniature, optical 2400 / 2420 (shaft / hollow shaft) Push-Pull 48

Miniature, magnetic 2430 / 2440 (shaft / hollow shaft) RS422 51

Compact, optical Sendix Base KIS40 / KIH40 (shaft / hollow shaft)) Push-Pull / RS422 54
open collector
3610 / 3620 (shaft / hollow shaft) Push-Pull / RS422 57 Incremental encoders
Plastic housing 3700 / 3720 (shaft / hollow shaft) Push-Pull / RS422 61

Standard, optical Sendix 5000 / 5020 (shaft / hollow shaft) Push-Pull / RS422 65
High temperature 5803 / 5823 (shaft / hollow shaft) Push-Pull / RS422 75

Sine wave output, with zero pulse 5804 / 5824 (shaft / hollow shaft) SinCos 80
Sine wave output, highly interpolable Sendix 5814 / 5834 (shaft / hollow shaft) SinCos 84
Sine wave output, SIL2 / PLd Sendix SIL 5814FS2 / 5834FS2 (shaft / hollow shaft) SinCos 87
Sine wave output, SIL3 / PLe Sendix SIL 5814FS3 / 5834FS3 (shaft / hollow shaft) SinCos 93
High resolution 5805 / 5825 (shaft / hollow shaft) Push-Pull / RS422 99
Stainless steel Sendix 5006 / 5026 (shaft / hollow shaft) Push-Pull / RS422 103
Large hollow shaft 5821 (hollow shaft) Push-Pull / RS422 107
ATEX / IECEx Sendix 7000 (shaft) Push-Pull / RS422 110

ATEX / IECEx, SIL2 / PLd Sendix SIL 7014FS2 (shaft) SinCos 113
ATEX / IECEx, SIL3 / PLe Sendix SIL 7014FS3 (shaft) SinCos 116
ATEX / IECEx, mining Sendix 7100 (shaft) Push-Pull / RS422 119

Large hollow shaft, A020 (hollow shaft) Push-Pull / RS422 / 122
optical SinCos
Robust A02H (hollow shaft) Push-Pull / RS422 / 126
SinCos

Heavy Duty, Shaft Sendix Heavy Duty H100 (shaft) Push-Pull / RS422 / 133
optical speed switch
Hollow shaft Sendix Heavy Duty H120 (hollow shaft) Push-Pull / RS422 / 138
optical fibre

Bearingless, magnetic RI20 / Limes LI20 (hollow shaft) Push-Pull / RS422 143
Zero pulse RI50 / Limes LI50 (hollow shaft) Push-Pull / RS422 146
