Absolute encoders - singleturn

Standard
ATEX / IECEx – zone 1 / 21, optical Sendix 7053 (shaft) SSI / BiSS
www.HydroSanatSharif.com
Technical data
Explosion protection ATEX SSI interface
EC type-examination certificate PTB09 ATEX 1106 X Output driver RS485 transceiver type
Category (gas) II 2 G Ex d IIC T4 - T6 Gb Permissible load / channel max. +/- 20 mA
Category (dust) II 2D Ex tb IIIC T135°C - T85°C Db IP6x Signal level HIGH typ 3.8 V
Directive 94/9/EC EN 60079-0:2009; LOW at I Load = 20 mA typ 1.3 V
EN 60079-1:2007; Resolution 10 ... 14 bit and 17 bit
EN 60079-31:2009 Code binary or gray
SSI clock rate 50 kHz ... 2 MHz
Explosion protection IECEx Monoflop time ) 15 µs
Certificate of conformity (CoC) IECEx PTB 13.0026 X Note: if clock starts cycling within monoflop time a second data transfer starts
Category (gas) Ex d IIC T4 - T6 Gb with the same data. If clock starts cycling after monoflop time, the data transfer
Category (dust) Ex tb IIIC T135°C - T85°C Db IP6x starts with updated values. The update rate depends on clock speed, data Absolute encoders
length and monoflop time.
IECEx IEC 60079-0:2007; singleturn
IEC 60079-1:2007; Data refresh rate resolution ) 14 bit < 1 µs
IEC 60079-31:2008 resolution * 15 bit 4 µs

Mechanical characteristics BiSS interface
Maximum speed 6000 min (continuous) Resolution 10 ... 14 bit and 17 bit
-1
Starting torque - at 20°C [68°F] < 0.05 Nm Code binary
-6
Mass moment of inertia 4.0 x 10 kgm 2 Clock rate up to 10 MHz
Load capacity of shaft radial 80 N Max. update rate < 10 µs, depends on the clock rate
axial 40 N and the data length
Weight approx. 1.3 kg [45.86 oz] Data refresh rate ) 1 µs
Protection acc. to EN 60529 IP67 Note: – bidirectional, factory programmable parameters are:
Working temperature range -40°C ... +60°C [-40 ... +140°F] resolution, code, direction, alarms and warnings
– CRC data verification
Material shaft stainless steel
flange / housing seawater durable Al,
type AlSiMgMn (EN AW-6082) SET input
cable PUR Input HIGH active
2
Shock resistance acc. to EN 60068-2-27 2500 m/s , 6 ms Input type comparator
2
Vibration resistance acc. to EN 60068-2-6 100 m/s , 55 ... 2000 Hz Signal level HIGH min. 60 % of +V
(+V = power supply) max. +V
LOW max. 25 % of +V
Electrical characteristics
Input current < 0.5 mA
Power supply 10 ... 30 V DC
Min. pulse duration (SET) 10 ms
Current consumption (no load) max. 45 mA
Timeout after SET signal 14 ms
Reverse polarity protection yes
for power supply Response time (DIR input) 1 ms
Short-circuit proof outputs yes 1) The encoder can be set to zero at any position by means of a HIGH signal on
the SET input. Other preset values can be factory-programmed.
CE compliant acc. to EMC guideline 2004/108/EC The SET input has a signal delay time of approximately 1 ms. Once the SET
ATEX guideline 94/9/EC function has been triggered, the encoder requires an internal processing time
RoHS guideline 2011/65/EU of approximately 15 ms before the new position data can be read.
DIR input Status output
A High signal switches the direction of rotation from the default CW to CCW. Output driver open collector, internal pull-up
The reverse function can also be factory-programmed. resistor 22 kOhm
If DIR is reversed when the device is already switched on, this will be Permissible load max. 20 mA
interpreted as an error. The status output switches to LOW. Signal level HIGH +V
LOW < 1 V
Power-ON time Active at LOW
After Power-ON, the device requires a time of approximately 150 ms before The status output serves to display various alarm or error messages.
valid data can be read. The status output is HIGH (open collector with internal pull-up 22 kOhm) in
normal operation.

1) Short-circuit with 0 V or output, only one channel at a time, power supply correctly applied.
