Incremental encoders

Standard
large hollow shaft, optical 5821 (hollow shaft) Push-Pull / RS422
www.HydroSanatSharif.com
Dimensions
Dimensions in mm [inch]

Flange with spring element, ø 58 [2.28]
Cable version, connection type 1

1 M1.6 / 5 [0.2] deep
2 4 x socket set screw M4x6 DIN 913 ) )
' '
3 Cylindrical pin 3m6x12 DIN 6325 included
4 Cable length 2 m [6.56‘] Incremental
5 Cable gland PG7 ƒ ƒ encoders

PD[ PD[ 5 ƒ 5 ƒ

Flange with spring element, ø 58 [2.28]
M12 connector version, connection type E

1 M1.6 / 5 [0.2] deep

2 Cylindrical pin 3m6x12 DIN 6325 included ) )

3 4 x socket set screw M4x6 DIN 913 ' '
4 Connector M12
ƒ ƒ

5 5
PD[ PD[ ƒ ƒ

© Fritz Kübler GmbH, subject to errors and changes. 02/2015 www.kuebler.com 109
