Absolute encoders – multiturn

Standard
ATEX / IECEx – mining, mechanical multiturn, optical Sendix 7163 (shaft) SSI / BiSS + SinCos
www.HydroSanatSharif.com
Terminal assignment

Interface Type of connection Features Cable (isolate unused wires individually before initial start-up)
Signal: 0 V +V C+ C- D+ D- SET DIR Stat ) )
2 1, 2, A, B SET, DIR
Cable marking: 1 2 3 4 5 6 7 8 9 YE/GN shield
+V: Encoder power supply +V DC DIR: Direction input: If this input is active, output values are counted
0 V: Encoder power supply ground GND (0 V) backwards (decrease) when the shaft is turning clockwise.
C+, C-: Clock signal Stat: Status output
D+, D-: Data signal ): Protective earth
SET: Set input. The current position becomes defined as position zero.

Dimensions
Dimensions in mm [inch]

Clamping / synchronous flange, ø 70 [2.76]
Shaft type 1 with axial cable outlet
! !
1 6 x M4, 10 [0.39] deep
2 Keyway for DIN 6885-A-4x4x25 key Absolute encoders
PD[ ƒ multiturn
ƒ
" "

> @ > @ > @ ƒ
K I J

# #

ƒ

$ $

Clamping / synchronous flange, ø 70 [2.76] !
!
Shaft type 2 with radial cable outlet [0 > @ WLHI %
%
1XW IU 3DVVIHGHU ',1 $ [ [
1 6 x M4, 10 [0.39] deep
ƒ
