Absolute encoders – multiturn

Compact
electronic multiturn, optical Sendix F3663 / F3683 (shaft / hollow shaft) SSI / BiSS
www.HydroSanatSharif.com
Order code 8.F3683 . X X X X . X X X 2 If for each parameter of an encoder the underlined preferred option is selected,
then the delivery time will be 10 working days for a maximum of 10 pieces.
Hollow shaft Type a b c d e f g Qts. up to 50 pcs. of these types generally have a delivery time of 15 working days.
a Flange c Interface / power supply e Code Optional on request
1 = with spring element, short, IP65 1 = SSI, BiSS / 5 V DC B = SSI, binary - surface protection
3 = with spring element, long, IP65 2 = SSI, BiSS / 10 ... 30 V DC C = BiSS, binary salt spray tested
2 = with stator coupling, IP65, 3 = SSI, BiSS + 2048 ppr. SinCos / 5 V DC G = SSI, gray - other singleturn
ø 46 mm [1.81“] 4 = SSI, BiSS + 2048 ppr. SinCos / 10 ... 30 V DC resolutions
5 = SSI, BiSS / 5 V DC, with sensor output f Resolution
b Hollow shaft 6 = SSI, BiSS + 2048 ppr. SinCos / 5 V DC, with sensor output (singleturn)
1 = ø 6 mm [0.24“] 7 = SSI, BiSS + 2048 ppr. RS422 / 5 V DC A = 10 bit ST
3 = ø 8 mm [0.32“] 8 = SSI, BiSS + 2048 ppr. RS422 / 10 ... 30 V DC 2 = 12 bit ST
4 = ø 10 mm [0.39“], blind hollow shaft 3 = 13 bit ST
2 = ø 1/4” d Type of connection 4 = 14 bit ST
1 = tangential cable, 1 m [3.28‘] PUR 7 = 17 bit ST
3 = tangential cable, 5 m [16.40‘] PUR
U = tangential cable, 10 m [32.81‘] PUR g Resolution

5 = tangential cable, 1 m [3.28‘] PUR (multiturn)
with M12 connector for central fastening, 8-pin 1) 2 = 12 bit MT
6 = 16 bit MT
4 = 24 bit MT
Absolute encoders

Mounting accessory for shaft encoders Order no.
Coupling Bellows coupling ø 19 mm [0.75“] for shaft 8 mm [0.32“] 8.0000.1102.0808 multiturn
Mounting accessory for hollow shaft encoders Order no.
Cylindrical pin, long With fixing thread 8.0010.4700.0000

6: > @ P
for torque stops

0 5

Connection technology Order no.
Connector, self-assembly (straight) M12 female connector with coupling nut 05.CMB 8181-0

Cordset, pre-assembled M12 female connector with coupling nut, 2 m [6.56‘] PUR cable 05.00.6051.8211.002M
Further accessories can be found in the accessories section or in the accessories area of our website at: www.kuebler.com/accessories.
Additional connectors can be found in the connection technology section or in the connection technology area of our website at: www.kuebler.com/connection_technology.

Technical data

Mechanical characteristics
Maximum speed Protection housing side IP67
shaft version without shaft seal (IP65) 12000 min -1 acc. to EN 60529 shaft side IP65 (solid shaft version opt. IP67)
-1
or blind hollow shaft version 10000 min (continuous) Working temperature range -40°C ... +90°C [-40°F ... +194°F]
shaft version with shaft seal (IP67) 10000 min -1 Materials shaft / hollow shaft stainless steel
-1
or hollow shaft version 8000 min (continuous) flange aluminium
Starting torque at 20°C [68°F] housing zinc die-cast
without shaft seal < 0.007 Nm cable PUR
with shaft seal (IP67) < 0.01 Nm Shock resistance acc. to EN 60068-2-27 2500 m/s , 6 ms
2
2
Shaft load capacity radial 40 N Vibration resistance acc. to EN 60068-2-6 100 m/s , 55 ... 2000 Hz
axial 20 N
Weight approx. 0.2 kg [7.06 oz]

1) Only with output circuits 1 and 2.
© Fritz Kübler GmbH, subject to errors and changes. 02/2015 www.kuebler.com 277
