Absolute encoders – multiturn

Standard
mechanical multiturn, optical Sendix 5868 / 5888 (shaft / hollow shaft) PROFINET IO
www.HydroSanatSharif.com

The multiturn encoders Sendix 5868 and 5888 with PROFINET
interface and optical sensor technology are ideal for use in all
applications with PROFINET technology.
The encoder supports the isochronous (IRT) mode and is therefore
ideal for real-time applications.

RoHS
2/22

-40°... +85°C IP
Mechanical Safety-Lock TM High rotational Temperature High protection High shaft load Shock / vibration Magnetic field Reverse polarity Optical sensor Surface protection
drive speed range level capacity resistant proof protection salt spray-tested
optional
Reliable Flexible Absolute encoders
• Ideally suited for all PROFINET applications thanks to the use • IRT-Mode. multiturn
of encoder profile 4.1. • Cycle time ) 1 ms.
• Perfect for use in harsh outdoor environments, as a result of • Firmware updater allows for easy expansion of characteristics
IP67 protection and rugged housing construction. without having to disassemble the encoder.
• Faster, easier error-free connection thanks to M12 connectors.

Order code 8.5868 . X X C 2 . C2 12 If for each parameter of an encoder the underlined preferred option is selected,
then the delivery time will be 10 working days for a maximum of 10 pieces.
Shaft version Type a b c d e Qts. up to 50 pcs. of these types generally have a delivery time of 15 working days.
a Flange b Shaft (ø x L), with flat c Interface / power supply e Fieldbus profile
1 = clamping flange, IP65 ø 58 mm [2.28“] 1 = 6 x 10 mm [0.24 x 0.39“] 1) C = PROFINET IO / 10 ... 30 V DC C2 = PROFINET IO
3 = clamping flange, IP67 ø 58 mm [2.28“] 2 = 10 x 20 mm [0.39 x 0.79“] 2)
2 = synchro flange, IP65 ø 58 mm [2.28“] 3 = 1/4“ x 7/8“ d Type of connection Optional on request
4 = synchro flange, IP67 ø 58 mm [2.28“] 4 = 3/8“ x 7/8“ removable bus terminal cover - Ex 2/22
5 = square flange, IP65 63.5 mm [2.5“] 2 = 3 x M12 connector, 4-pin - surface protection
7 = square flange, IP67 63.5 mm [2.5“] salt spray tested

Order code 8.5888 . X X C 2 . C2 12 If for each parameter of an encoder the underlined preferred option is selected,
then the delivery time will be 10 working days for a maximum of 10 pieces.
Hollow shaft Type a b c d e Qts. up to 50 pcs. of these types generally have a delivery time of 15 working days.
a Flange b Blind hollow shaft c Interface / power supply e Fieldbus profile
1 = with spring element, long, IP65 3 = ø 10 mm [0.39“] C = PROFINET IO / 10 ... 30 V DC C2 = PROFINET IO
2 = with spring element, long, IP67 4 = ø 12 mm [0.47“]
3 = with stator coupling, IP65 ø 65 mm [2.56“] 5 = ø 14 mm [0.55“] d Type of connection Optional on request
4 = with stator coupling, IP67 ø 65 mm [2.56“] 6 = ø 15 mm [0.59“] removable bus terminal cover - Ex 2/22
5 = with stator coupling, IP65 ø 63 mm [2.48“] 8 = ø 3/8“ 2 = 3 x M12 connector, 4-pin - surface protection
6 = with stator coupling, IP67 ø 63 mm [2.48“] 9 = ø 1/2“ salt spray tested

1) Preferred type only in conjunction with flange type 2.
2) Preferred type only in conjunction with flange type 1.
© Fritz Kübler GmbH, subject to errors and changes. 02/2015 www.kuebler.com 343
