Absolute encoders – multiturn

Standard
ATEX / IECEx – zone 1 / 21, mechanical multiturn, optical Sendix 7063 (shaft) SSI / BiSS + SinCos
www.HydroSanatSharif.com
Technical data
Explosion protection ATEX SSI interface
EC type-examination certificate PTB09 ATEX 1106 X Output driver RS485 transceiver type
Category (gas) II 2 G Ex d IIC T4 - T6 Gb Permissible load / channel max. +/- 20 mA
Category (dust) II 2D Ex tb IIIC T135°C - T85°C Db IP6x Signal level HIGH typ 3.8 V
Directive 94/9/EC EN 60079-0:2009; LOW at I Load = 20 mA typ 1.3 V
EN 60079-1:2007; Resolution singleturn 10 ... 14 bit and 17 bit
EN 60079-31:2009 Number of revolutions (multiturn) 4096 (12 bit)
Code binary or gray
Explosion protection IECEx SSI clock rate 50 kHz ... 2 MHz
Certificate of conformity (CoC) IECEx PTB 13.0026 X Monoflop time < 15 µs 2)
Category (gas) Ex d IIC T4 - T6 Gb Note: if clock starts cycling within monoflop time a second data transfer starts
Category (dust) Ex tb IIIC T135°C - T85°C Db IP6x with the same data. If clock starts cycling after monoflop time, the data transfer
starts with updated values. The update rate depends on clock speed, data
IECEx IEC 60079-0:2007;
IEC 60079-1:2007; length and monoflop time.
IEC 60079-31:2008 Data refresh rate ST resolution ) 14 bit < 1 µ
ST resolution * 15 bit 4 µs
Mechanical characteristics
BiSS interface
-1
Maximum speed 6000 min (continuous) Absolute encoders
Starting torque – at 20°C [68°F] < 0.05 Nm Resolution singleturn 10 ... 14 bit and 17 bit multiturn
-6
Mass moment of inertia 4.0 x 10 kgm 2 Number of revolutions (multiturn) 4096 (12 bit)
Code binary
Load capacity of shaft radial 80 N
axial 40 N Clock rate up to 10 MHz
Weight approx. 1.3 kg [45.86 oz] Max. update rate < 10 µs, depends on the clock rate
and the data length
Protection acc. to EN 60529 IP67
Data refresh rate ) 1 µs
Working temperature range -40°C ... +60°C [-40 ... +140°F]
Note: – bidirectional, factory programmable parameters are:
Material shaft stainless steel
flange / housing seawater durable Al, resolution, code, direction, alarms and warnings
type AlSiMgMn (EN AW-6082) – CRC data verification
cable PUR
2
Shock resistance acc. to EN 60068-2-27 2500 m/s , 6 ms SET input
2
Vibration resistance acc. to EN 60068-2-6 100 m/s , 55 ... 2000 Hz Input HIGH active
Input type Comparator
Electrical characteristics Signal level HIGH min. 60 % of +V
(+V = Power supply) max. +V
Power supply 10 ... 30 V DC
LOW max. 25 % of +V
Current consumption (no load) max. 45 mA
Input current < 0.5 mA
Reverse polarity protection yes Min. pulse duration (SET) 10 ms
for power supply
Timeout after SET signal 14 ms
Short-circuit proof outputs yes 1)
Response time (DIR input) 1 ms
CE compliant acc. to EMC guideline 2004/108/EC
ATEX guideline 94/9/EC The encoder can be set to zero at any position by means of a HIGH signal on
RoHS guideline 2011/65/EU the SET input. Other preset values can be factory-programmed.
The SET input has a signal delay time of approximately 1 ms. Once the SET
function has been triggered, the encoder requires an internal processing time
DIR input of approximately 15 ms before the new position data can be read.
A HIGH signal switches the direction of rotation from the default CW to CCW.
The reverse function can also be factory-programmed. Status output
If DIR is reversed when the device is already switched on, this will be Output driver open collector, internal pull-up
interpreted as an error. The status output switches to LOW. resistor 22 kOhm
Permissible load max. 20 mA
Power-ON time Signal level HIGH +V
LOW < 1 V
After Power-ON, the device requires a time of approximately 150 ms before
valid data can be read. Active at LOW
The status output serves to display various alarm or error messages. The status
output is HIGH (open collector with internal pull-up 22 kOhm) in normal operation.

1) Short-circuit with 0 V or output, only one channel at a time, power supply correctly applied.
