Absolute encoders - singleturn

Standard
ATEX / IECEx – mining, optical Sendix 7153 (shaft) SSI / BiSS
www.HydroSanatSharif.com
Technical data
Explosion protection ATEX SSI interface
EC type-examination certificate IBExU 14 ATEX 1047 X Output driver RS485 transceiver type
Category I M2 Ex d I/IIC T4 - T6 Mb Permissible load / channel max. +/- 20 mA
Directive 94/9/EC EN 60079-0:2012; Signal level HIGH typ 3.8 V

Explosionsschutz EN 60079-1:2007 LOW at I Load = 20 mA typ 1.3 V
Resolution 10 ... 14 bit and 17 bit
Explosion protection IECEx Code binary or gray
Certificate of conformity (CoC) IECEx IBE 14.0023 X SSI clock rate 50 kHz ... 2 MHz
Category I M2 Ex d I/IIC T4 - T6 Mb Monoflop time ) 15 µs
IECEx IEC 60079-0:2011; Note: if clock starts cycling within monoflop time a second data transfer starts
IEC 60079-1:2007 with the same data. If clock starts cycling after monoflop time, the data transfer
starts with updated values. The update rate depends on clock speed, data
length and monoflop time.
Mechanical characteristics Data refresh rate resolution ) 14 bit < 1 µs
-1
Maximum speed 6000 min (continuous) resolution * 15 bit 4 µs
Starting torque - at 20°C [68°F] < 0.05 Nm
Mass moment of inertia 4.0 x 10 kgm 2 BiSS interface
-6
Load capacity of shaft radial 80 N Resolution 10 ... 14 bit and 17 bit
axial 40 N Code binary
Weight approx. 1.3 kg [45.86 oz] Clock rate up to 10 MHz
Protection acc. to EN 60529 IP67 Max. update rate < 10 µs, depends on the clock rate
Working temperature range -40°C ... +60°C [-40 ... +140°F] and the data length
Material shaft stainless steel Data refresh rate ) 1 µs
flange / housing stainless steel Note: – Bidirectional, factory programmable parameters are:
cable PUR resolution, code, direction, alarms and warnings
2
Shock resistance acc. to EN 60068-2-27 2500 m/s , 6 ms – CRC data verification
2
Vibration resistance acc. to EN 60068-2-6 100 m/s , 55 ... 2000 Hz
SET input
Input HIGH active
Electrical characteristics
Input type comparator
Power supply 10 ... 30 V DC
Signal level HIGH min. 60 % of +V
Current consumption (no load) max. 45 mA
(+V = power supply) max. +V
Reverse polarity protection yes LOW max. 25 % of +V
for power supply
Input current < 0.5 mA
Short-circuit proof outputs yes 1)
Min. pulse duration (SET) 10 ms
CE compliant acc. to EMC guideline 2004/108/EC Timeout after SET signal 14 ms
ATEX guideline 94/9/EC
RoHS guideline 2011/65/EU Response time (DIR input) 1 ms
The encoder can be set to zero at any position by means of a HIGH signal on
the SET input. Other preset values can be factory-programmed.
DIR input The SET input has a signal delay time of approximately 1 ms. Once the SET
A HIGH signal switches the direction of rotation from the default CW to CCW. function has been triggered, the encoder requires an internal processing time
The reverse function can also be factory-programmed. of approximately 15 ms before the new position data can be read.
If DIR is reversed when the device is already switched on, this will be
interpreted as an error. The status output switches to LOW.
Status output
Output driver open collector, internal pull-up
Power-ON time resistor 22 kOhm
After Power-ON, the device requires a time of approximately 150 ms before Permissible load max. 20 mA
valid data can be read. Signal level HIGH +V
LOW < 1 V
Active at LOW
The status output serves to display various alarm or error messages.
The status output is HIGH (open collector with internal pull-up 22 kOhm) in
normaloperation.

1) Short-circuit with 0 V or output, only one channel at a time, power supply correctly applied.
